Kubota D1105-E2BG Electricity Supplier electric generator diesel 7kw 9kVA
1. Kubota Engine With Stamford Alternator
2. High Efficiency , Low Fuel Consumption
3.12 Months Warranty ,CE Approved
Four Stroke D1105-E2BG-CHN-1 Engine Kubota Diesel Generator 10KVA
Specifications:
1. Composed of of Kubota diesel engine and Stamford or Leroy Somer alternator
2. 12V DC start motor and storage battery
3. Brushless, Self-excited, IP23, insulation class H alternator
4. 40°C radiator as standard, 50°C is optional
5. Key start panel control system as standard, digital auto-start panel is optional
6. 8-hour operation base tank
7. All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load, 110% load and all protection function
|
Prime Power
|
8KW/10KVA
|
Standby Power
|
8.8KW/11KVA
|
|
Rated Speed
|
1500RPM
|
Output Frequency
|
50HZ
|
|
Phase
|
3
|
Rated Voltage
|
400V
|
|
Engine Model
|
D1105-E2BG-CHN-1
|
Alternator Model
|
PI044E
|
|
Fuel Consumption of 100% load
|
3.2L/H
|
Fuel Consumption of 75% load
|
2.4L/H
|
|
Voltage Regulation Rate
|
≤±1%
|
Random Voltage Rate
|
≤±1%
|
|
Frequency Regulation Rate
|
≤±5%
|
Random Frequency Variation
|
≤±0.5%
|
|
Dimension (open type)
|
1000×600×820(mm)
|
Weight (open type)
|
300kg
|
|
Dimension(silent type)
|
1300×650×900(mm)
|
Weight (silent type)
|
400kg
|
|
Engine Model
|
D1105-E2BG-CHN-1
|
|
Number of Cylinder
|
3
|
|
Cylinder arrangement
|
Vertical in-line
|
|
Cycle
|
Four Stroke
|
|
Aspiration
|
Natural Aspiration
|
|
Bore×Stroke (mm×mm)
|
78×78.4
|
|
Displacement (L)
|
1.123L
|
|
Compression Ratio
|
22.0:1
|
|
Prime Power/Speed(KW/rpm)
|
8.5/1500
|
|
Standby Power/Speed(KW/rpm)
|
9.4/1500
|
|
Speed Governor
|
Electrical
|
|
Cooling System
|
Water-cooled, 4°C Radiator As Standard, 50°C Is Optional
|
|
Speed Stability(%)
|
≤5%
|
|
Total Lubrication System Capacity (L)
|
5.6
|
|
Coolant Capacity(without radiator) (L)
|
5.5
|
|
Fuel Consumption at 100% Load(g/kwh)
|
3.2(at 1500RPM)
|
|
Starter Motor
|
DC12V
|
|
Alternator
|
AC12V
|
