Salt Spray corrosion test chamber is adapted to the surface treatment of various materials, including paint, electroplating, organic and inorganic coating, anode processing, antirust oil and so on, to test the corrosion resistance of products with anti-corrosive treatment.
|
Model
|
HY-60
|
HY-90
|
HY-120
|
HY-160
|
HY-200
|
|
Inner box size:
(L×W×H) cm
|
60×45×40
|
90×60×50
|
120×100×50
|
160×100×50
|
200*100*50
|
|
Outside box size:
(L×W×H)cm
|
108*108*65
|
135×112×75
|
190×128×125
|
230×128×125
|
270*128*125
|
|
Temperature range
|
35℃~55℃;
|
|
Test chamber temperature
|
NSS ACSS 35℃±1℃(CASS 50℃±1℃)
|
|
Saturated air barrel temperature
|
NSS ACSS 47℃±1℃(CASS 63℃±1℃)
|
|
Temperature fluctuations
|
≤±0.5°C
|
|
Temperature uniformity
|
≤±2.0°C
|
|
Lab volume
|
110L
|
270L
|
600L
|
800L
|
1000L
|
|
Brine tank capacity
|
15L
|
25L
|
40L
|
65L
|
80L
|
|
Multiple safety protection devices
|
Water shortage; over temperature ;phase protection
|
|
Standard accessories
|
Test salt, measure bucket, tool etc 1 set
|
|
weight (kg)
|
60
|
90
|
180
|
280
|
450
|
|
Power
|
AC220V 1Φ20A
|
AC220V 1Φ20A
|
AC220V 1Φ30A
|
AC220V 3Φ15A
|
AC220V 3Φ15A
|
Packaging:
-The glass parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent.
|
Shipping method
|
Note
|
|
Express
|
Door to door, very convenient, don't need to clearance or pick-up
|
|
By air
|
Airport to airport, you need to do the customs clearance and pick up the
goods at your local airport, which you can have a local shipping agent to do for you.
|
|
By sea
|
Port to port and you need to do the customs clearance and pick-up the goods
at your local port, which you can have a local shipping agent to do for you.
|
