Large Outdoor Architectural Aluminum LED Post Top Light
The 200A series high performance LED post top light for use in large outdoor areas like auto dealership parking lots lighting, corporate parks, and retail settings to replace 250W MH fixture. Tested beyond industry standards, these LED fixtures feature IES Type V Specification Grade Optics, which provide a wider field of view and directs the light down so it is good for the environment and wildlife as well. A truly "GREEN" product, this LED fixture is ETL/DLC/RoHS Compliant, has no mercury, or lead, and emits no UV light.
Morstar is a trusted,global company with a keen insight into the market. We konw lighting and provide products with excellent quality, reliability and functionality.
FEATURES:
• Die cast Aluminum house, excellent thermal control
• High-performance Philips light source and UL drive output
• Dimmable: 1-10V DC/PWM/Resistor (3 IN 1)
• Air-flow fins for maximum heat dissipation
• Compatible with standard 2 3/8" and 3" tenons
• Beam Angle Type V
• Certified to U.S. and Canadian standards. IP65 Rated
• With Sensor: Microwave sensor Daily sensor available
|
SPECIFICATION
|
EAL201A-50W
|
EAL202A-75W
|
EAL203A-100W
|
EAL204A-150W
|
EAL205A-170W
|
|
Power Consumption
|
50W
|
75W
|
100W
|
150W
|
170W
|
|
Equivalent Wattage
|
175W HID
|
250W HID
|
400W HID
|
600W HID
|
600W HID
|
|
Lumens Delivered
|
6,500 lm
|
9,750 lm
|
13,000 lm
|
19,500 lm
|
22,100 lm
|
|
Efficacy
|
130 lm/W
|
|
CRI
|
>75
|
|
Color Temperature
|
3000K / 4000K /5000K /5700K
|
|
Input Voltage
|
120-277V
|
CONSTRUCTION:
• Precision die-cast aluminum With excellent external cooling fins
• Clear tempered glass lens,Type V distribution
• Chip and fade resistant polyester powder coat finish
• LED performance exceeds industry standards for chromatic
RECOMMENDED USE:
• Parking lots
• Corporate parks
• Retail areas
WARRANTY:
7-year standard warranty with labor allowance* (further details available at www.morstar.com/warranties)
*Warranty Limitations: Product must be rated for the application per the Product Data Sheet (PDS); operated <16 hrs; in ambient of
-40°F to 122°F.
APPLICATION:
FAQ：
1. What`s the warranty of the lamp?
- For UL/DLC items we provide 5 years warrantly, others have a 2 years warrantly.
2.Can I have a sample order for led light?
-Yes, we welcome sample order for led light to test and check quality.
Mixed samples are acceptable.
3. What about the lead time?
--Samples can be delivered in about 1 week, and bulk orders will take about 2 to 3 weeks.
4. What about the quality?
- Select high quality materials.
- 48 hours aging test to end defective products.
- Quality control testing before shipping.
- Good package to insure safety.
5. Where are your main markets?
- North American and Latin American.And we have LED lighting distribution warehouses in California，Texas and Michigan
6. Can you design new model?
- Yes, we can open new mould according to your drawings and produce.
7.Any suggestion? Please contact us.
