large outdoor tents for wedding events
1.Popular shaped tent for all events
2.Weather resistant with keder tracked tops and sidewalls
3.Easy to integrate heating and A/C
4.Roof and gable vent is available
5.A variety of accessories available for customization
The Specification of large tents for events:
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
HS30/4-5
|
30
|
4
|
8.9
|
5
|
18°
|
10.7
|
100
|
|
HS40/4-5
|
40
|
4
|
10.5
|
5
|
18°
|
11.5
|
100
|
|
HS50/4-5
|
50
|
4
|
12.1
|
5
|
18°
|
11.5
|
100
|
|
HS60/4-5
|
55
|
4
|
13
|
5
|
18°
|
11.5
|
100
|
|
Main frame Profile
|
350x120x5mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Twin Steel Plate
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
Available sizes:
● Clear span available from 3m to 60m.
● Length: adjustable by 3m unit (SS & WS series) or 5m unit (for other series).
Features:
● No exterior guy ropes or staking required.
● No poles inside, 100% interior space be used.
● Roof and gable vent is available.
● Relocatable, easy to install, dismantle and transport.
● Full line accessories available.
Frame:
● No maintenance required.
● Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
● All steel connectors including small parts have galvanized finishing above 60um.
● Modular character for diverse combination and expansion.
Cover:
● Kedered roof fabric and sidewalls provide weather-proof tight coverings.
● Bar tensioning roof & sidewalls system.
● Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
