LED Full Color Large Screen
Product Name: LED large screen, LED indoor
full color, LED outdoor full color, LED monochrome, LED two-color, transparent
LED.
Product specifications: non-standard size,
can be customized according to needs.
Core equipment: dome display equipment,
fisheye lens, multimedia control equipment, interactive system.
Application direction: large-scale
exhibition halls, exhibitions, urban planning halls, science and technology
museums, museums, new product launches, promotional events, stage, wedding weddings,
and traditional multimedia such as office buildings, performance venues, and
plazas.
LED large screen (full color) function
introduction:
1. Video playback can display true color
dynamic video images; high-fidelity playback of video recorders, DVD players
(VCD, DVD, LD) and other video programs; LED large screen with superimposed
text, animation and still images on the video screen; Editing devices enable
real-time editing and playback of panoramas, close-ups, slow motions, and
effects. Brightness, contrast, saturation, and chromaticity can be adjusted by
software with an adjustment range of 4096. Has an image freeze function. The
LED color screen has three display modes: video overlay (VGA+Video), video
(Video), and VGA. With horizontal / vertical position compensation. With
display synchronization.
2. computer graphics and text information
playback function can display a variety of computer information, text,
graphics, pictures and two, three-dimensional animation, etc.; LED color screen
has a rich playback mode, display scrolling information, notifications,
slogans, etc., storage data information capacity The display body can open
multiple windows, display calendar, clock, insert single-line mobile text;
there are a variety of Chinese fonts and fonts to choose from, LED color screen
can also input English, Spanish, French, German, Greek, Japanese, Latin and
Russian, and many other foreign languages; the broadcast system has multimedia
software, which can flexibly input and broadcast a variety of information; the
broadcast mode has left and right scrolling, scrolling up and down, pushing
left and right, pushing up and down, diagonally pushing, spreading More than 20
kinds of fan type, rotation, zoom, etc. Display network data information
through a network connection.
3. LED display network function, equipped
with network interface, can be connected to the computer, share network
resources, with standard audio signal output interface to achieve audio and
video synchronization.
LED large screen (full color) structure features:
a .New material: The unit box of the LED
color screen is made of special steel profiles.
b. Good rain resistance: When the steel
profile is designed, four sealing structures are added. Except for one special
sealing strip, the other three channels are in the form of diversion trough to
prevent rainwater from entering the tank.
c. High dimensional accuracy: the
geometrical and dimensional design deviation between the cabinets is only 0.02
mm. Therefore, the unit cabinets are almost the same size. After assembly, the
gaps are even, and all the LED cabinets are in the same façade. Therefore, The
entire screen is very flat and works well.
d. Easy installation: No matter the
connection between the box and the frame or the unit box, the front and rear
special steel plates are bolted. The signal connection and power connection
between the cabinet and the cabinet are all connected by waterproof air plugs,
and the LED indoor color screen is convenient and quick to operate and has
higher stability.
e. Easy to disassemble and maintain: After
the whole screen of the LED large screen (full color) is installed, if you want
to remove any one of the unit cabinets, you only need to remove the special
joints of the four corners of the box. The normal maintenance takes 3 minutes.
Very convenient.
f. Corrosion resistance: The steel box body
is corrosion resistant and can be corroded for 20 years. Increased product
life.
