3.2V90Ah Prismatic LiFePO4 Cell
|
Item
|
Specification
|
Remarks
|
|
Nominal Capacity
|
105Ah
|
@0.2C discharge , 2.5V cut off
|
|
Typical Capacity
|
104Ah
|
@0.2C discharge , 2.5V cut off
|
|
Minimum Energy
|
332Wh
|
@0.2C discharge , 2.5V cut off
|
|
Nominal Voltage
|
3.2V
|
|
|
Charge Voltage
|
3.65±0.02V
|
|
|
Charge Mode
|
CC/CV
|
|
|
Charge
|
Standard charge : 0.2C
|
Charge at 0.2C to 3.65V, then 3.65V (constant voltage) until the charge current is less than 0.02C cut off
|
|
Rapid charge : 1.0C
|
Charge at 1C charge to 3.65V, then 3.65V (constant voltage) until the charge current is less than 0.02C, cut off.
|
|
Discharge
|
Standard Discharge : 0.2C
|
Constant Current 0.2C, cut-off Voltage 2.5V
|
|
Rapid Discharge : 1.0C
|
Constant Current 1C, cut-off Voltage 2.5V
|
|
Max. Charge Current
|
1.0C
|
1.0C(45℃≥T≥ 10℃) ; 0.2C(10℃≥T≥0℃)
|
|
Cont. Discharge Current
|
2.0C to 2.5V
|
0.5C(50℃≥ T≥ 45℃) ; 2.0C(45℃≥T≥5℃) ; 0.2C(5℃≥T≥-20℃)
|
|
Max. Discharge Current
|
3.0C
|
3.0C(45℃≥T≥5℃)
|
|
Inner Resistance
|
≤ 2.0mΩ
|
1kHz AC Method
|
|
Weight (Approx.)
|
1980±30g
|
|
|
Dimensions
|
Thickness(max): 36mm；Width(max): 150mm ；Length(max): 200mm
|
|
Cycle Life
|
≤ 2000 times
|
@0.1C discharge, 100% DOD
|
|
Operating Temperature
|
Charge: 0 ~ 45℃
|
|
|
Discharge : -20 ~60℃
|
|
Storage Temperature
|
1 year : 10~20℃
|
At 50% SOC
|
|
3 months : -0~25℃
|
|
1 month : -20~30℃
|
|
Storage Humidity
|
5%≤ RH≤ 85%
|
|
