MATX Intel P55 LGA 1156 motherboard

  • Intel P55 chipset, LGA 1156 motherboard
  • Dual channel DDR3, maximum capacity up to 8GB
  • SATA2 3GB/s ports


  • MemoryDual channel DDR3 up to 8GB
  • ChipsetIntel H55 Express chipset
  • CPU socketLGA 1156

Product Details

100MB LAN
5.1 channel Audio

LGA 1156 socket

Intel LGA 1156 socket makes you
have more selections on processors

Heatsink

Big Heat sink let tempreture stay down.
Computer works more stable.

Dual channel DDR2

2 * 240-pin DDR2 DIMM slots
Maximum up to 4GB capacity.

All solid capacitors

Brand new all material,
Completely all solid capacitors,
Say "No" to half solid capacitors,
More power supply to CPU.

Support CPU model numbers:
µArch Code name Brand name Model (list) Frequency Cores/threads Max. memory speed
Nehalem (45nm) Lynnfield Core i5 i5-7xx 2.66–2.8 GHz 4/4 DDR3-1333
Core i7 i7-8xx 2.8–3.07 GHz 4/8
Xeon L34xx 1.86 GHz 4/4 or 4/8
X34xx 2.4–3.07 GHz
Westmere (32nm) Clarkdale Celeron G1xxx 2.26 GHz 2/2 DDR3-1066
Pentium G6xxx 2.80 GHz 2/2
Core i3 i3-5xx 2.93–3.33 GHz 2/4 DDR3-1333
Core i5 i5-6xx 3.2–3.6 GHz 2/4
Xeon L34xx 2.0–2.27 GHz 2/4 DDR3-1066
Product Name # of Cores Max Turbo Frequency Processor Base Frequency Cache Processor Graphics
Intel® Core™ i7-860S 4 3.46 GHz 2.53 GHz 8 MB Intel® Smart Cache
Intel® Core™ i7-870 4 3.60 GHz 2.93 GHz 8 MB Intel® Smart Cache
Intel® Core™ i7-860 4 3.46 GHz 2.80 GHz 8 MB Intel® Smart Cache
Intel® Core™ i5-750 4 3.20 GHz 2.66 GHz 8 MB Intel® Smart Cache
Intel® Core™ i5-750S 4 3.20 GHz 2.40 GHz 8 MB Intel® Smart Cache
Intel® Core™ i5-760 4 3.33 GHz 2.80 GHz 8 MB Intel® Smart Cache
Intel® Core™ i7-870S 4 3.60 GHz 2.66 GHz 8 MB Intel® Smart Cache
Intel® Core™ i7-875K 4 3.60 GHz 2.93 GHz 8 MB Intel® Smart Cache
Intel® Core™ i7-880 4 3.73 GHz 3.06 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3430 4 2.80 GHz 2.40 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3440 4 2.93 GHz 2.53 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3450 4 3.20 GHz 2.66 GHz 8 MB Intel® Smart Cache
Intel® Xeon® L3426 4 3.20 GHz 1.86 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3460 4 3.46 GHz 2.80 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3470 4 3.60 GHz 2.93 GHz 8 MB Intel® Smart Cache
Intel® Xeon® X3480 4 3.73 GHz 3.06 GHz 8 MB Intel® Smart Cache
Intel® Core™ i5-660 2 3.60 GHz 3.33 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i5-661 2 3.60 GHz 3.33 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i5-670 2 3.73 GHz 3.46 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i3-540 2 3.06 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i5-650 2 3.46 GHz 3.20 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i3-530 2 2.93 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i5-680 2 3.86 GHz 3.60 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i3-550 2 3.20 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i5-655K 2 3.46 GHz 3.20 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Core™ i3-560 2 3.33 GHz 4 MB Intel® Smart Cache Intel® HD Graphics for Previous Generation Intel® Processors
Intel® Pentium® G6950 2 2.80 GHz 3 MB Intel® Smart Cache
Intel® Pentium® G6960 2 2.93 GHz 3 MB Intel® Smart Cache
Intel® Pentium® G6951 2 2.80 GHz 3 MB Intel® Smart Cache
Intel® Xeon® Processor L3406 2 2.53 GHz 2.26 GHz 4 MB Intel® Smart Cache
