MCX516A-GCAT QSFP28 PCIE3.0 X16
Key Features
- Tag matching and rendezvous offloads
- Adaptive routing on reliable transport
- Burst buffer offloads for background checkpointing
- NVMe over Fabric offloads
- Backend switch elimination by host chaining
- Embedded PCIe switch
- Enhanced vSwitch/vRouter offloads
- Flexible pipeline
- RoCE for overlay networks
- PCIe Gen 4.0 support
- RoHS compliant
- ODCC compatible
- Various form factors available
Applications
ConnectX-5 Ethernet network interface cards provide high performance and flexible solutions with up to two ports of 50GbE connectivity, 750ns latency, up to 200 million messages per second (Mpps), and a record setting 197Mpps when running an open source Data Path Development Kit (DPDK) PCIe (Gen 4.0). For storage workloads, ConnectX-5 delivers a range of innovative accelerations, such as Signature Handover (T10-DIF) in hardware, an embedded PCIe Switch, and NVMe over Fabric target offloads. ConnectX-5 adapter cards also bring advanced Open vSwitch offloads to telecommunications and cloud data centers to drive extremely high packet rates and throughput with reduced CPU resource consumption, thus boosting data center infrastructure efficiency.
Specification
| Model |
MCX516A-GCAT |
| Max Speed |
50GbE |
| Ports |
Dual |
| PCI |
PCIe3.0 x16 |
| Connector Type |
QSFP28/QSFP+/QSFP |
| Size |
2.71 in. x 5.6 in. (68.90mm x 142.24 mm) – low profile |
| Connector |
Dual QSFP28 (copper and optical) |
| Passive Cable |
14.7W |
| Non-operational |
-40°C to 70°C |
| Data Rate |
1/10/25/40/50 Gb/s Ethernet |
Lead time
| Quantity (pieces) |
1-10 |
10-60 |
>60 |
| Lead time (days) |
3 |
3-5 |
To be negotiated |
About Us
STOR TECHNOLOGY LIMITED founded in 2007, focusing on providing hardware solutions for cloud computing ,cloud storage,data centre, security monitor, customized server and other fields. Our main products are Raid Card, HBA Card,Fiber Card,Network Card,Hard Drives,CPU. We can provide long-term good after sales service for customers. ODM orders Welcom!
Our Advantages
FAQ
Q1: What payment method do you accept?
A1: Trade assurance, T/T, Western Union
Q2: What is the mininum order Quantity(MOQ）?
A2: We can sell one piece for testing.
Q3: When is the lead time of your products?
A3: we have stock, we can provide fast delivery within 2~3 days for 10pcs.
Q4: How about the warranty service?
A4: 3 year for wanrranty free.
