General
|
|
|
Device Type
|
Switch - 24 ports -
managed
|
|
Enclosure Type
|
Desktop,
rack-mountable, wall-mountable 1U
|
|
Subtype
|
Gigabit Ethernet
|
|
Ports
|
24 x SFP + 2 x SFP+
|
|
Performance
|
Bandwidth: 44 Gbps ¦
Forwarding performance: 65 Mpps
|
|
Remote
Management Protocol
|
SNMP 1, SNMP 2, SNMP
3
|
|
Authentication
Method
|
Secure Shell (SSH),
TACACS+
|
|
Features
|
Full
duplex capability, layer 2 switching, ARP support, MPLS support, VLAN
support, Syslog support, Class-Based Weighted Fair Queuing (CBWFQ), DHCP
snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List
(ACL) support, Quality of Service (QoS), Dynamic ARP Inspection (DAI)
|
|
Compliant
Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE
802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE
802.3ah, IEEE 802.1ag
|
|
RAM
|
1 GB
|
|
Flash Memory
|
64 MB
|
|
Status
Indicators
|
Port status, power,
system, alarm
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
1 x 1000Base-T RJ-45
management ¦ 1 x console RJ-45 management ¦ 2 x SFP+ ¦ 24 x SFP (mini-GBIC)
|
|
Expansion
Slots
|
1 (total) / 1 (free)
x SD Memory Card
|
|
Power
|
|
|
Power Device
|
Internal power supply
|
|
Installed Qty
|
0 (installed) / 2
(max)
|
|
Power
Redundancy
|
Optional
|
|
Miscellaneous
|
|
|
Compliant
Standards
|
NOM,
VCCI Class A ITE, EN55024, EN55022 Class A, CCC, FCC Part 15, AS/NZS 3548,
EN300-386, UL 60950-1, IEC 60950-1, KCC, CSA C22.2 No. 60950-1
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5 in
|
|
Depth
|
20.4 in
|
|
Height
|
1.7 in
|
|
Weight
|
14.48 lbs
|
|
Manufacturer
Warranty
|
|
|
Service &
Support
|
Limited warranty - 90
days
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
32 °F
|
|
Max Operating
Temperature
|
122 °F
|
|
Humidity Range
Operating
|
5 - 95%
(non-condensing)
|
|
Min Storage
Temperature
|
-13 °F
|
|
Max Storage
Temperature
|
158 °F
|
|
Model No
|
ME-3800X-24FS-M
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
