Bearing No.
|
Dimensions(mm)
|
Ball
dia
|
a0
mis.
angle
|
Load ratings
(KN)
|
Weight
≈ kg
|
|
d
|
B
|
C1
|
d2
|
d3-6g
|
h
|
L1
|
L2
|
L7
|
Dynamic
|
Static
|
|
SA5C
|
5
|
6
|
4.5
|
21
|
M5
|
36
|
16
|
46.5
|
12
|
10
|
13
|
3.6
|
4.6
|
0.017
|
|
SA6C
|
6
|
6
|
4.5
|
21
|
M6
|
36
|
16
|
46.5
|
12
|
10
|
13
|
3.6
|
6.9
|
0.017
|
|
SA8C
|
8
|
8
|
6.5
|
24
|
M8
|
42
|
21
|
54
|
13
|
13
|
15
|
5.8
|
12.9
|
0.029
|
|
SA10C
|
10
|
9
|
7.5
|
29
|
M10
|
48
|
26
|
62.5
|
16
|
16
|
12
|
8.6
|
17.6
|
0.044
|
|
SA12C
|
12
|
10
|
8.5
|
34
|
M12
|
54
|
28
|
71
|
18
|
18
|
10
|
11
|
24.5
|
0.066
|
|
SA15C
|
15
|
12
|
10.5
|
40
|
M14
|
63
|
34
|
83
|
22
|
22
|
8
|
18
|
36
|
0.121
|
|
SA15ET-2RS
|
15
|
12
|
10.5
|
40
|
M14
|
63
|
34
|
83
|
22
|
22
|
8
|
18
|
36
|
0.121
|
|
SA17C
|
17
|
14
|
11.5
|
46
|
M16
|
69
|
36
|
92
|
24
|
25
|
10
|
22
|
45
|
0.172
|
|
SA17ET-2RS
|
17
|
14
|
11.5
|
46
|
M16
|
69
|
36
|
92
|
24
|
25
|
10
|
22
|
45
|
0.172
|
|
SA20C
|
20
|
16
|
13.5
|
53
|
M20X1.5
|
78
|
43
|
104.5
|
27
|
29
|
9
|
31
|
60
|
0.283
|
|
SA20ET-2RS
|
20
|
16
|
13.5
|
53
|
M20X1.5
|
78
|
43
|
104.5
|
27
|
29
|
9
|
31
|
60
|
0.283
|
|
SA25C
|
25
|
20
|
18
|
64
|
M24x2
|
94
|
53
|
126
|
33
|
35.5
|
7
|
51
|
83
|
0.504
|
|
SA25ET-2RS
|
25
|
20
|
18
|
64
|
M24x2
|
94
|
53
|
126
|
33
|
35.5
|
7
|
51
|
83
|
0.504
|
|
SA30C
|
30
|
22
|
20
|
73
|
M30x2
|
110
|
65
|
146.5
|
37.5
|
40.7
|
6
|
65
|
110
|
0.835
|
|
SA30ET-2RS
|
30
|
22
|
20
|
73
|
M30x2
|
110
|
65
|
146.5
|
37.5
|
40.7
|
6
|
65
|
110
|
0.835
|
|
SA35ET-2RS
|
35
|
25
|
22
|
82
|
M36x3
|
140
|
82
|
181
|
41
|
47
|
6
|
112
|
146
|
1.41
|
|
SA40ET-2RS
|
40
|
28
|
24
|
92
|
M39x3
|
150
|
86
|
196
|
47
|
53
|
7
|
140
|
180
|
1.86
|
|
SA45ET-2RS
|
45
|
32
|
28
|
102
|
M42x3
|
163
|
92
|
214
|
52
|
60
|
7
|
180
|
240
|
2.57
|
|
SA50ET-2RS
|
50
|
35
|
31
|
112
|
M45x3
|
185
|
104
|
241
|
60
|
66
|
6
|
220
|
290
|
3.58
|
|
SA60ET-2RS
|
60
|
44
|
39
|
135
|
M52x3
|
210
|
115
|
277.5
|
75.5
|
80
|
6
|
345
|
450
|
5.73
|
|
SA70ET-2RS
|
70
|
49
|
43
|
160
|
M56x4
|
235
|
125
|
315
|
95
|
92
|
6
|
440
|
610
|
7.94
|
|
SA80ET-2RS
|
80
|
55
|
48
|
180
|
M64x4
|
270
|
140
|
360
|
105.5
|
105
|
6
|
567
|
750
|
12.06
|
Body: Carbon steel, Zinc plated, chromate treated
SA..C: Mounted with GE..C type of radial spherical plain bearings
Sliding contact surfaces: Steel/PTFE composite
