Bearing No.
|
Dimensions(mm)
|
Ball
dia
|
a0
mis.
angle
|
Load ratings
(KN)
|
weight
≈Kg
|
|
d
H7
|
B
|
C1
|
d1
|
d2
|
d3-6g
|
h
|
L1
|
L2
|
Dynamic
|
Static
|
|
SPOS5EC
|
5
|
8
|
6
|
7.7
|
16
|
M5
|
33
|
20
|
41
|
11.11
|
13
|
3.3
|
4.8
|
0.012
|
|
SPOS6EC
|
6
|
9
|
6.75
|
8.9
|
18
|
M6
|
36
|
22
|
45
|
12.7
|
13
|
4.7
|
6.8
|
0.019
|
|
SPOS8EC
|
8
|
12
|
9
|
10.3
|
22
|
M8
|
42
|
25
|
53
|
15.87
|
14
|
7.7
|
12.3
|
0.032
|
|
SPOS10EC
|
10
|
14
|
10.5
|
12.9
|
26
|
M10
|
48
|
29
|
61
|
19.05
|
13
|
10.4
|
17.3
|
0.054
|
|
SPOS12EC
|
12
|
16
|
12
|
15.4
|
30
|
M12
|
54
|
33
|
69
|
22.22
|
13
|
13.5
|
22.7
|
0.085
|
|
SPOS14EC
|
14
|
19
|
13.5
|
16.8
|
34
|
M14
|
60
|
36
|
77
|
25.4
|
16
|
17.2
|
28.2
|
0.126
|
|
SPOS16EC
|
16
|
21
|
15
|
19.3
|
38
|
M16
|
66
|
40
|
85
|
28.58
|
15
|
21
|
35.1
|
0.185
|
|
SPOS18EC
|
18
|
23
|
16.5
|
21.8
|
42
|
M18X1.5
|
72
|
44
|
93
|
31.75
|
15
|
25
|
43.2
|
0.260
|
|
SPOS20EC
|
20
|
25
|
18
|
24.3
|
46
|
M20x1.5
|
78
|
47
|
101
|
34.92
|
14
|
29.8
|
50.3
|
0.340
|
Can supply rod ends with different pitch or accuracy of thread.
For left-hand thread, suffix "L" is added to bearing numbers. e.g.:SPOS20ECL M20×1.5L-6g:
