Cutting accuracy: ± 0.10mm/m
Diagonal accuracy:±0.25mm/m
Maximum glass size: 350*350mm （could do customized size）
Minimum glass size: 20*20mm (or customized 15*15mm)
Cutting thickness: 0.7-8mm
Cutter life: 30,000-50,000m (Straight line)
Operator 1 people
Cutter box adjustment
Place small glass under the cutter wheel, the upper limit screw is loosened and limit screw is rotated, the angle between the low end of knife box and glass surface is 60°－75°, and then the position limiting screw is tightened. In addition, the cutting pressure can be adjusted by the knurling mother in the lower part of the rotary cutter box.
