Mini Skidsteer Log Grapple squeezes into tight spaces and gets the job done efficiently with the ideal attachment for landscapers and tree service contractors who need hauling strength through narrow passages.
- The Lod Grapple features a spring-centered return that twists when turning corners but stays straight when grabbing logs, a tight grapple closure for small branches, and lateral or in-line grapple positioning for smooth log handling.
- This Log Grapple is designed to fit the universal attachment plate of the following make of Mini Skidsteers only: Toro, Vermeer, Ramrod, Boxer, Ditch Witch (Will not fit 1550 Ditch Witch)
- From Forest to Fireplace, it Provides Heavy Duty Equipment to Get the Job Done!
|
Lift Capacity
|
1000lbs (454kg)
|
|
Engine HP Range
|
12-50
|
|
Recommended Hydraulic Flow
|
3gpm (11lpm)
|
|
Grapple Opening
|
3"-40" (8-102cm)
|
|
Clamp Force
|
9400lbs (4264kg)
|
|
Rotator/Pivot Rating
|
6750lbs (3062kg)
|
|
Total Weight
|
285lbs (130kg)
|
|
Dimensions (LxWxH)
|
47"x44"x40" (120x112x102cm)
|
|
Mounting System
|
Mini Loader Mount Plate
|
Bypass Grapple
Grapple tines fold together as tight as 3" (7.5cm), ensuring easy handling of smaller logs and branches
Spring-Centered Grapple with Locking Positions
The grapple twists when turning corners but stays straight when grabbing logs. Includes lateral and in-line lock positions.
Cantilever Cradle
Leverage and secure your load with the serrated cradle when lifting logs in-line.
