mini slim 36w ip67 led driver 12v 3 amp power supply with ce etl rohs
AC-DC Energy transfer, 12V @3.0A 36W output, 217*29*21mm super slim size IP67 12v 36w led driver.
Specifications
-
Input:100~265vAC / 47-63HZ
-
Working mode: Constant voltage
-
Efficiency: 82%
-
RippleI & Noise (max.) : 150mVp-p
-
Voltage Tolerance : ±5%
-
Line Regulation : ±1%
-
Load Regulation : ±2%
-
Case material: Aluminum housing
-
Waterproof rate: IP67
-
Produt cord:connecting terminal(IP20) / 18AWG*20CM
-
CE, ETL, ROHS approval
-
2 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)
Product parameters
|
Model
|
Input voltage(AC V)
|
Working Frequency (Hz)
|
Output voltage (DC V)
|
Output Current
|
Output power
(DC W)
|
Working Temp.
|
Protection grade
|
|
SMT-012-036VW
|
100-265V
|
47~63Hz
|
12±0.5
|
3.0A
|
36W
|
-25~50°C
|
IP67
|
|
SMT-024-036VW
|
100-265V
|
47~63Hz
|
24±0.5
|
1.5A
|
36W
|
-25~50°C
|
IP67
|
|
SMT-012-060VW
|
100-265V
|
47~63Hz
|
12±0.5
|
5A
|
60w
|
-25~50°C
|
IP67
|
|
SMT-024-060VW
|
100-265V
|
47~63Hz
|
24±0.5
|
2.5A
|
60W
|
-25~50°C
|
IP67
|
What is constant voltage led driver?
A Constant Voltage LED Driver 12V & 24v can be used to power LED lights that have constant current drivers already within the system or resistors . 'Constant voltage' refers to the ability to fluctuate output current to maintain a set voltage. So you need some type of constant voltage power supply that can convert your AC household voltage down to a safe DC voltage
