Digital - Analog Conversion Module Screw Terminal Block Type AJ65SBT2B-64DA
The high-accuracy, high-resolution CC-Link 4CH analog output module saves man-hours and space.
Features
-
4 analog output channels
-
High accuracy within the system accuracy of ±0.3% (0 to 55℃)
-
Fast conversion at the maximum conversion rate of 200 μs/CH
-
High resolution with the voltage output of 0.333 mV and the electric current output of 0.95 μA
-
A built-in automatic function for following transmission speed saves you from setting transmission speed.
-
A two-piece structure is adopted for the external terminal block. The terminating resistance is built in the module to save wiring and man-hours.
Station type Remote device station
Number of stations occupied 1 station
CC-Link version Ver. 1
External dimensions 50(H)×122(W)×54(D)[mm]
Mass 0.25kg
