Part Number AJ65VBTCU-68ADIN
Features
-
Compatible with Ver. 2
On the conventional model, three stations occupied eight channels, whereas a single station occupies eight channels on this module.
It can also be used as conventional Ver. 1 depending on the setting of the rotary switch.
-
Highly accurate
This input module performs A/D conversion with an accuracy of ±0.3% to the maximum digital output value when the working ambient temperature is between 0℃ and 55℃, or with an accuracy of ±0.2% to the maximum digital output value when the working ambient temperature is 25±5℃.
-
The analog input range can be switched for each channel, and input/output conversion characteristics can be changed.
-
A high resolution of 1/±4000 is realized.
By switching the input range, the resolution of digital values can be set to either 1/4000 or 1/±4000 (AJ65VBTCU-68ADVN only), providing high-resolution digital values.
-
Sampling or averaging can be designated.
Sampling or averaging can be designated for each channel as the conversion method.
|
Station type
|
Remote device station
|
|
Number of stations occupied
|
Ver. 1 mode, 3 stations Ver. 2 mode, 1 station
|
|
CC-Link version
|
Ver.1, Ver.2
|
|
External dimensions
|
115(H)×41(W)×67(D)[mm]
|
|
Mass
|
0.17kg
|
