Rated output 200W / 0.2kW - 22-bit (equivalent to 4194304ppr) feedback - Rated current 1.3A - Supply voltage 200Vac class - Rated torque 0.64Nm nominal - Rated rotational speed 3000rpm - 60x60mm flange mounting - IP65 - with 4-pin rectangular connector - rated for 0...+40°C ambient - equivalent to HGKR23K
| Primary brand |
Mitsubishi Electric |
| Main function |
AC servo motor |
| Product series / family name |
MELSERVO J4 series |
| Sub-range name |
HG-KR series |
| Functions |
AC brushless rotary servo motor |
| Design |
keyed shaft
built-in absolute feedback encod. (22-bit)
low inertia / small power capacity
natural cooling |
| Supply voltage (AC) |
200Vac class |
| Rated current |
1.3A |
| Rated active power (kW) |
200W / 0.2kW |
| Rotational speed |
3000rpm
6000rpm (maximum) |
| Torque |
0.64Nm nominal |
| Maximum torque |
2.2Nm |
| Moment of inertia |
0.0000221kg.m2 (0.221kg.cm2) |
| Connection type |
4-pin rectangular connector |
| Mounting mode |
60x60mm flange mounting |
| Resolution |
22-bit (equivalent to 4194304ppr) feedback |
| Degree of protection |
IP65 |
| Dimensions |
H77.1mm x W60mm x D106.6mm |
| Ambient air temperature for operation |
0...+40 °C |
| Ambient air temperature for storage |
-15°C...+70 °C |
| Maximum radial load |
245 N |
| Maximum axial load |
98 N |
| Maximum current |
4.6 A |
| Equivalent to |
HGKR23K |
| Compliant with standard(s) |
CE marking
TUV Rheinland
cULus
UL
KC
EN61800-3
EN60034-1
EN62061
SILCL3
EN50581
UL1004-1
UL1004-6
CSA
KC
EAC |
