Features :
Special Chute Design:
vacuum surface plating .hard to wear and corrosion resistance
Electronic Anti-jamming system:
signal transmission design, make it perfect working for different environment.
High-quality distinction system:
High definition 2048pixel camera, precision at 0.02mm
Intelligent Operation surface:
Japan Pro-face interface with multi- modes saved for your different sorting
Adjustable light source tech :
advanced & adjustable LED light source ensure the accurate obtaining. Special design make it long term using, low energy consumption and perfect performance, no need additional radiator
National Patented Ejector:
Patent ejector, rapid response, minimum air-consumption
Dust cleaning system:
Special design and dust absorption design with better surrounding for sorting
Technical data :
|
Name
|
MX1
|
MX2
|
MX3
|
MX4
|
MX5
|
MX7
|
MX10
|
MX12
|
|
Channels
|
63
|
126
|
189
|
252
|
315
|
441
|
630
|
756
|
|
Capacity（t/h）
|
0.6~1
|
1~2
|
1.5~3.5
|
3~6
|
4~7
|
7~10
|
10~14
|
12~16
|
|
Sorting accuracy
|
≥99%
|
≥99.99%
|
≥99.99%
|
≥99.99%
|
≥99.99%
|
≥99.99%
|
≥99.99%
|
≥99.99%
|
|
Optimized carryover(bad:good)
|
﹥8:1
|
﹥8:1
|
﹥8:1
|
﹥8:1
|
﹥8:1
|
﹥8:1
|
﹥8:1
|
AC200-240V 50/60Hz
|
|
Voltage(V)
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
AC220V 50/60Hz
|
|
Power （KW）
|
﹤1.5
|
﹤2
|
﹤2.4
|
﹤2.7
|
﹤3.0
|
﹤4.0
|
﹤4.0
|
﹤8.0
|
|
Air Pressure（MPa）
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
|
Air Consumption（㎥/min）
|
﹤0.8
|
﹤1.25
|
﹤2.5
|
﹤2.8
|
﹤3
|
﹤3.6
|
﹤3.6
|
﹤3.6
|
|
Weight（Kg）
|
500
|
700
|
800
|
1000
|
1250
|
1600
|
2500
|
2550
|
|
Dimension（L×W×H）(mm)
|
1114×1525×1392
|
1314×1557×1737
|
1516×1570×1850
|
1850×1570×1850
|
2206×1613×1930
|
2765×1570×1850
|
3686×1572×2048
|
4668X1595X2040
|
Application Examples :
