Product Item: Multi-functional ABB robot palletizer system
Main application area
Packing, palletizing, transportation of material, upload and download of material, management of machines
Advantages
1. Shorten cycle time
IRB 460 is the fastest 4 axis multifunction industrial robot in the world which can significantly shorten the cycle time of each part work and greatly enhance production efficiency. The arriving distance of this robot can be 2.4m and available loading 110kg. The highest handling movement can be 2190 times/hour when loading 60kg (400mm X 2000mm X 400mm) which is 15% faster than other product under similar conditions.
2. Running with high accuracy
IEB 460 runs steadily with excellent path accuracy which matched movement control software of ABB patent QuickMove and TrueMove. The robot is also available even for the most sensitive product and ensures that cycle time is not affected.
3. Small footprint and high output
IRB 460 robot is designed compacted which can shorten 20% of the distance to product pallet compared with the similar products that speed and loading is nearly. Only this index can improve production efficiency of 3%.
4. Low cost of the robot and high production efficiency
IRB 460 robot is produced based on automobile industry with steady structure and good design which uptime long and low maintenance costs. ABB also provide RoboCare 3 years warranty program which ensure the production available under the premise of no additional cost.
Specification
|
Loading
|
110kg
|
|
Arriving Distance
|
2.4m
|
|
Axis
|
4
|
|
Protection Grade
|
IP67
|
|
Installation
|
Floor standing
|
|
Model of IRC5 controller
|
Single
|
|
Integrated electrical signal source
|
Optional
|
|
Integrated gas source
|
Optional
|
|
Robot base size
|
1007*720mm
|
|
Robot weight
|
925kg
|
|
Repeat locating accuracy
|
0.20mm
|
|
Repeat circulation accuracy
|
0.11mm
|
Movement
|
Axis movement
|
Working scope
|
Fastest speed
|
|
Axis 1
|
+165°~ -165°
|
145°/s
|
|
Axis 2
|
+85°~ -40°
|
110°/s
|
|
Axis 3
|
+120°~ -20°
|
120°/s
|
|
Axis 4
|
+300°~ -300°
|
400°/s
|
Electrical connections and working environment
|
Power Pressure
|
200~600V, 50-60Hz
|
|
Power Consumption
|
ISO cube 3.67kW
|
|
Operation environment
|
+-0°C to +45°C
|
|
Transport and storage environment
|
-25°to +55°C
|
|
Short time(Not more than 24 hours) environment
|
Can be +70°C
|
|
Relative humidity
|
Highest 95%
|
|
Noise level
|
<70 dB(A)
|
|
Safe
|
With monitor, emergency stop and safe function
|
|
Radiation
|
EMC/EMI shield
|
FAQ:
Q: How to get an accurate quotation ?
A: Please provide us at least the following basic information: packed product type, filled amount, desired bag format, desired output so that we can give you detail offer of robot palletizer system. Of course, the more facts we know, the more accurate quotation will be.
Q:How many branches does the company have around the world? A:The company has only one branch, currently we are looking for business partners and agents especially in regions of Southeast Asia,Middle East,South America. If you are interested in it,please contact us freely.
Q: In what most exotic country is your packaging machine placed?
A: We have packaging machines worldwide, the most interesting countries are for example Indonesia,Malaysia,Turkey Etc.
Q: Do you participate on international trade fairs? Which?
A: Every year we participate packing exhibition in Indonesia,India etc. Besides, we are going to expand more in the year to come.
Q: Can your machine be customized ?
A: Yes, we are a professional manufacturer specialized in palletizing robot, packaging machine, conveyor etc. for more than 10 years and we have a strong design&technical team. We can design and manufacture as per your requirements.
Q: Do you provide packing materials?
A: No, we only provide recommendations to customers on the suitability of packaging films. Furthermore we supply the customers with plan printing on the foil according to which the foil supplier prints the graphics. The customer ensures graphical design and printing at his own expense.
Q: Payment terms, MOQ, warranty, Trade Terms
A: Payment terms: 30% down payment against order by T/T, the balance of 70% to be paid on delivery.
Minimum order quantity: 1 set, FOB Shanghai
Delivery time: about 20-30 working days after receipt of formal order and 30% deposit.
Warranty: 12 months following delivery. We offer online service 24 hours all day long, Skype, Email etc. You can contact us any time, if urgently, please call us.
Q: What’s policy for guarantee and broken parts ?
A: As for machine products, our company provides 12 months for all mechanical parts with the exception of electrical and electronic parts and those subjects to normal wear and tear. Meanwhile, the guarantee starts from the shipment (B/L date). The guarantee is intended limited to the replacement of the broken part after checking the construction fault. The inspection of the causes of the trouble or the breakdown of the parts is exclusively up to the manufacturing company. All in all, our company can offer you assured products.
