Successful application of this module requires a reasonable working knowledge of the Rockwell Automation
ControlLogix hardware, the MVI56-DFCMR Module and the application in which the combination is to be used. For
this reason, it is important that those responsible for implementation satisfy themselves that the combination will meet
the needs of the application without exposing personnel or equipment to unsafe or inappropriate working conditions.
The MVI56-DFCMR module requires the following minimum hardware and
software components:
-
Rockwell Automation ControlLogix™ processor, with compatible power
supply and one free slot in the rack, for the MVI56-DFCMR module. The
module requires 800mA of available power.
-
Rockwell Automation RSLogix 5000 programming software version 2.51 or
higher.
-
Rockwell Automation RSLinx communication software
-
Pentium® II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
-
Supported operating systems:
-
Microsoft Windows XP Professional with Service Pack 1 or 2
-
Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
-
Microsoft Windows Server 2003
-
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
-
100 Mbytes of free hard disk space (or more based on application
requirements)
-
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
-
CD-ROM drive
-
ProSoft Configuration Builder, HyperTerminal or other terminal emulator
program.
Prosoft MVI56-DFCMR
Prosoft MVI56DFCMR
Email:sales3@amikon.cn
In order for the MVI56-DFCMR module to function, a minimum amount of
configuration data must be transferred to the module. The following table
provides an overview of the different types of configuration data that the module
will require, depending on the operating modes to be supported.
More details please contact us !!!
|
