Interface
Provided
|
|
|
Qty
|
6
|
|
Type
|
Serial (RS-232)
|
|
Comments
|
Uplink
|
|
Connector Type
|
RJ-45
|
|
Networking
|
|
|
Type
|
Switch
|
|
Remote
Management Protocol
|
CLI
|
|
Status
Indicators
|
Status
|
|
Ports Qty
|
48
|
|
Features
|
Access
Control List (ACL) support, Ethernet Virtual Private Network (EVPN), Hot
Standby Router Protocol (HSRP) support, IGMP snooping, Multiple Spanning Tree
Protocol (MSTP) support, Open Shortest Path First (OSPF), Per-VLAN Rapid
Spanning Tree (PVRST), Source-Specific Multicast (SSM), Virtual Extensible
LAN (VXLAN), VLAN support, VXLAN tunnel endpoints (VTEP) support
|
|
Routing
Protocol
|
ECMP, IGMP, MSDP,
Multiprotocol BGP, RIP, RIP-2
|
|
MAC Address
Table Size
|
96K entries
|
|
Subcategory
|
Network hubs and
switches
|
|
Advanced
Switching
|
Layer 3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Rack-mountable
|
|
Subtype
|
10 Gigabit Ethernet
|
|
Miscellaneous
|
|
|
Rack Mounting
Kit
|
Included
|
|
Compliant
Standards
|
AS/NZS
60950-1, AS/NZS CISPR22:2004 Class A, CISPR 22 Class A, CISPR 24, CNS
13438(95) Class A, CSA C22.2 No. 60950-1 Second Edition, EMC, EN 300386, EN
60950-1 Second Edition, EN55024, EN61000-3-2, EN61000-3-3, FCC CFR47 Part 15,
GB 4943, ICES-003 Class A, IEC 60950-1 Second Edition, KN22 Class A, RoHS
6/6, UL 60950-1 Second Edition, VCCI Class A
|
|
Height (Rack
Units)
|
1
|
|
Included
Accessories
|
Grounding kit
|
|
Color Category
|
Silver
|
|
Cable
|
|
|
Connectivity
Details Type
|
Console cable
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
32 °F
|
|
Max Operating
Temperature
|
104 °F
|
|
Humidity Range
Operating
|
5 - 95%
(non-condensing)
|
|
Min Storage
Temperature
|
-40 °F
|
|
Max Storage
Temperature
|
158 °F
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
|
|
Packaged
Quantity
|
1
|
|
Product Line
|
Cisco Nexus
|
|
Model
|
92160YC-X
|
|
Brand
|
Cisco
|
|
Power Device
|
|
|
Frequency
Required
|
50/60 Hz
|
|
Installed Qty
|
0
|
|
Max Supported
Qty
|
2
|
|
Nominal
Voltage
|
AC 120/230 V
|
|
Power
Redundancy
|
Yes
|
|
Power
Redundancy Scheme
|
N+1
|
|
Type
|
Internal power supply
|
|
Hot-Plug
|
Hot-plug
|
|
Service
|
|
|
Support
Details Type
|
Limited warranty
|
|
Support
Details Service Included
|
Advance parts
replacement
|
|
Support
Details Full Contract Period
|
1 year
|
|
Dimensions
& Weight
|
|
|
Width
|
17.3 in
|
|
Depth
|
22.5 in
|
|
Height
|
1.7 in
|
|
Weight
|
14.11 lbs
|
|
Service &
Support
|
|
|
Type
|
1 year warranty
|
|
Cable Details
|
|
|
Included Qty
|
1
|
|
Capacity
|
|
|
Type
|
Virtual Routing and
Forwarding (VRF) entries
|
|
Value
|
4096
|
|
Flash Memory
|
|
|
Installed Size
|
20 MB
|
|
Performance
|
|
|
Type
|
Bandwidth
|
|
Value
|
3.2 Tbps
|
|
Ports
|
|
|
Qty
|
48
|
|
Type
|
10 Gigabit SFP+
|
|
Ports (2nd)
|
|
|
Qty
|
6
|
|
Type
|
40 Gigabit QSFP+
(uplink)
|
|
Ports (3rd)
|
|
|
Qty
|
4
|
|
Type
|
100 Gigabit QSFP
|
|
RAM
|
|
|
Installed Size
|
16 GB
|
|
Service &
Support Details
|
|
|
Response Time
|
10 days
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
