Decoding function
- Supports H.265 Main Profile Level5.1、H.264 Baseline / Main / High Profile Level5.0、MPEG4 SP L0 ~ L3 / ASP L0-L5、MJPEG、JPEG Baseline decoding.
- Supports
4 channel 4K / 16 channel 1080P / 32 channel 720P / 64 channel D1 video decoding. Supports 4K, 500W, 300W, 200W, 130W and other standard video decoding.
- Supports PAL / NTSL other standard formats.
- Supports standard ONVIF access.
- Supports video RTSP streaming.
- Supports for video file playback.
- Compatible
with all standard ONVIF network camera, network video server protocol (NVR) and other video sources.
Encoding function：
- Supports HDMI signal coding.
- Supports the input signal H.264 Baseline, Main,
High Profile Level5.1 standard coding.
- Supports MJPEG / JPEG Baseline coding.
- Supports encoding 1080P, 720P resolution, etc.
- When encoding support resolution and frame rate adjustable.
- Supports encrypting the encoded video stream.
Output
function
- Supports two HDMI2.0 output interfaces; backward compatible HDMI1.3 and other versions.
- 1 channel HDMI2.0 output supports 3840 × 2160 @ 60fps, 1 channel HDMI2.0 output 1080P @ 60fps. Single-screen supports up to 64 split display.
- The equipment comes with 8 inch high screen direct display, support 1024*600 resolution; support 36 split screen video output.
Audio
- With 1-channel audio input and 1 channel audio output.
- Supports 16bit voice input and output.
Network
- With 1 10/100/1000Mbps adaptive network port, connect the network to achieve the signal input. Alarm：
- Support RS485 extended access alarm device, Support single machine 8092 channel. alarm input and output management.
- Support alarm linkage.
- Support platform linkage.
USB Interface
Three USB2.0 interfaces
- Support keyboard, mouse access, support mouse operation interface; mouse access, HDMI1 port in the
video directly superimposed operation interface, intuitive and easy to operate equipment.
- Access to external storage device, such as mobile hard disk, U disk.
Others
- With 4 dimensional joystick, you can easily and easily operate PTZ, camera, ball machine and other equipment.
Take the shuttle, including inside and outside the knob, can directly operate NVR/DVR equipment (SDK) Provide SDK/ control protocol, access to the client's required platforms and systems
- Support device configuration, remote backup and recovery, support remote key upgrade.
- Support equipment, cloud control, cloud backup, remote control, etc..
- Support remote / local configuration file import and export.
