Product Item: Nalift 3000kg Diesel Forklift Truck with Side Shift And Fork Positioner
· Nalift diesel forklift trucks standard with integral side shifter, fork positioner, hydraulic brake, Krupp channel steel, etc
· Great for outdoor use. Nalift diesel trucks are not adversely affected by wet or damp weather.
· Less down time. If fuel level is low, you simply fill the tank. No need to lose time charging a battery.
· Better performance. Acceleration, forklift speed, driveline torque at low RPM, and other performance capabilities are superior and it can easily handle any hydraulic additions.
· Lower noise and emission. Yanmar 4TNE92/4TNE98 engine provides better mechanical performance, lower exhaust emission.
· Better visibility. The Germany Krupp channel steel is narrower and the mast were built wider. There is nothing blocking the operator’s front and rear view.
· Less maintenance issues. Nalift diesel forklift requires less scheduled and repair maintenance and has longer engine life compared to propane models.
Nalift Diesel Forklift Specifications
|
Features
|
Manufacturer
|
|
|
NALIFT
|
|
Model
|
|
|
FD30
|
|
Capacity
|
|
KG
|
3000
|
|
Load center
|
|
MM
|
500
|
|
Power
|
|
|
Diesel
|
|
Drive
|
|
|
Seated operation
|
|
Tyres (f/r)
|
|
|
Solid tyre
|
|
Number of tyres (f/r)
|
|
|
2x2
|
|
Size
|
Max. fork height
|
|
MM
|
3000
|
|
Free lift
|
|
MM
|
135
|
|
Fork size
|
T x W x L
|
MM
|
45*120*1070
|
|
Fork distance
|
|
MM
|
1070/240
|
|
Mast tilt degree
|
α/β
|
Degree
|
6/11
|
|
Overall length
|
|
MM
|
2775
|
|
Overall width
|
|
MM
|
1240
|
|
Max. height mast lowered
|
|
MM
|
2015
|
|
Max. height mast extended
|
|
MM
|
4220
|
|
Overhead guard height
|
|
MM
|
2170
|
|
Turning radius
|
|
MM
|
2430
|
|
Load distance(distance from center line of front axle to vertical planof fork)
|
|
MM
|
485
|
|
Length of rear frame
|
|
MM
|
595
|
|
Right angle stack access
|
|
MM
|
2915
|
|
Performance
|
Max. drive speed (load) f/r
|
|
KM/H
|
18.5/18.5
|
|
Max. drive speed (unload) f/r
|
|
KM/H
|
19.0/19.0
|
|
Lift speed (load)
|
|
MM/S
|
600
|
|
Lift speed (unload)
|
|
MM/S
|
670
|
|
Lower speed (load)
|
|
MM/S
|
540
|
|
Lower speed (unload)
|
|
MM/S
|
570
|
|
Max. traction force (load)
|
|
KG
|
19500(1990)
|
|
Max traction force (unload)
|
|
KG
|
10600(1080)
|
|
Max.traction force (1.5km/h) (load)
|
|
KG
|
17000(1730)
|
|
Gradeability (1.5km/h)
|
|
%
|
24
|
|
Gradeability (load)
|
|
%
|
27
|
|
Gradeability (unload)
|
|
%
|
20
|
|
Weight
|
Total weight
|
|
KG
|
4290
|
|
Full load (front)
|
|
KG
|
6270
|
|
Full load (rear)
|
|
KG
|
1020
|
|
Unload (front)
|
|
KG
|
1530
|
|
Unload (rear)
|
|
KG
|
2760
|
Tyres
|
Tyre number (f/r)
|
|
|
2/2
|
|
Tyre size front
|
|
|
28x9-15
|
|
Tyre size rear
|
|
|
6.5-10
|
|
Wheelbase
|
|
MM
|
1700
|
|
Wheel tread front
|
|
MM
|
1010
|
|
Wheel tread rear
|
|
MM
|
965
|
|
Height of load backrest
|
|
MM
|
1220
|
|
Roof guard clearance
|
|
MM
|
1055
|
|
Rear counterweight height
|
|
MM
|
1130
|
|
Center height of tie rod pin
|
|
MM
|
335
|
|
Pedal height
|
|
MM
|
495/730
|
|
Full load ground clearance (min)(mast)
|
|
MM
|
115
|
|
Full load ground clearance(wheelbase center)
|
|
MM
|
185
|
|
Tilt degree (frame/rear counterweight)
|
|
%
|
62/49
|
|
Foot brake
|
|
|
Hydraulic
|
|
Hand brake
|
|
|
Foot-operated
|
|
Driving
|
Battery voltage/capacity
|
|
V/AH
|
12/80
|
|
Control
|
Engine brand/model
|
|
YANMAR
|
4TNE92/4TNE98
|
|
Device
|
Engine power
|
|
KW
|
32.8/43.7
|
|
Engine torquer
|
|
N.m
|
135.4~149.4/177.6~196.3
|
|
Cylinder number-cylinder diameter x stroke
|
|
MM
|
4--92X100/4-98X110
|
|
Piston displacement
|
|
L
|
2.659/3.319
|
|
Fuel capacity
|
|
L
|
60
|
|
Model of transmission
|
|
|
Dynamic gear-shift
|
|
Transmission switch (f/r)
|
|
|
1/1
|
|
Working pressure (attachment)
|
|
Mpa(kg/cm2)
|
15.7(160)
|
|
Standrad
|
Integral side shifter
|
|
|
|
Attachments
|
Fork positioner
|
|
|
|
