General
|
|
Dimention
|
123x60x35mm
|
|
Weight
|
220g
|
|
Frequency Band
|
LTE FDD: Band 1,3,5,8
|
|
LTE TDD: Band 34,38,39,40,41
|
|
WCDMA/HSPA+: Band1,8
|
|
GSM/GPRS/EDGE: 900/1800MHz
|
|
Data Transmission
|
|
LTD FDD Rel.9
|
150Mbps DL/50Mbps UL(Cat4)
|
|
LTD TDD Rel.9
|
112Mbps DL/10Mbps UL(Cat4)
|
|
UMTS/HSPA+Rel.6
|
UMTS:384kbps DL/384kbps UL
|
|
HSPA+:21Mbps DL(Cat14)/5.76Mbps UL(Cat6)
|
|
GPRS/EDGE Rel.5
|
GPRS:85.6kbps DL/85.6kbps UL(multi-slot lass12)
|
|
Frequency Power
|
|
Mode
|
Band
|
Tx Power(dBm)
|
Note
|
|
GSM
|
GSM 900
|
32.5
|
±1dB
|
|
DCS 1800
|
29.5
|
±1dB
|
|
WCDMA
|
Band I
|
23.5
|
±1dB
|
|
Band VIII
|
23.5
|
±1dB
|
|
LTE FDD
|
Band 1
|
23
|
±1dB
|
|
Band 3
|
23
|
±1dB
|
|
Band 5
|
23
|
±1dB
|
|
Band 8
|
23
|
±1dB
|
|
LTE TDD
|
Band 34
|
23
|
±1dB
|
|
Band 38
|
23
|
±1dB
|
|
Band 39
|
23
|
±1dB
|
|
Band 40
|
23
|
±1dB
|
|
Band 41
|
23
|
±1dB
|
|
Receiving Sensitivity
|
|
Mode
|
Band
|
Rx Sensitivity(dBm) Typical
|
Note
|
|
GSM
|
GSM 900
|
-108
|
BER＜2.43%
|
|
DCS 1800
|
-108
|
BER＜2.43%
|
|
WCDMA
|
Band I
|
-111
|
BER＜0.1%
|
|
Band VIII
|
-111
|
BER＜0.1%
|
|
LTE FDD
|
Band 1
|
-100
|
10MHz Band width
|
|
Band 3
|
-100
|
10MHz Band width
|
|
Band 5
|
-100
|
10MHz Band width
|
|
Band 8
|
-101
|
10MHz Band width
|
|
LTE TDD
|
Band 34
|
-101
|
10MHz Band width
|
|
Band 38
|
-100
|
10MHz Band width
|
|
Band 39
|
-101
|
10MHz Band width
|
|
Band 40
|
-100
|
10MHz Band width
|
|
Band 41
|
-100
|
10MHz Band width
|
