Overview
Brand: Nokia
MPN: 470139A
Model: FPMA
Discription: Flexi Power Module (FPMA) is an optional module. It comprises FPMA mechanics and AC and DC interfaces. FPMA includes AC connection box, DC cable set,
and a support frame for the actual power sub-modules (FPAA and FPBA).The actual power sub- modules are the following:
-
Flexi Power AC/DC sub-module 200-240 V AC(FPAA) ；The main function of the FPAA is to provide the BTS modules with 48V DC power from
AC supply. The FPMA can house up to four AC/DC rectifiers, each having output power
of 1 kW 48V DC.
-
Flexi Power Battery sub-module(FPBA)； The Flexi Power Battery Sub-Module (FPBA) is a separate optional sub-module used
together with the FPAA. The FPMA can house up to three battery sub-modules.
The Maximum number of sub-module in an FPMA is four.
