North Benz Truck Beiben Dump Truck
Engine Weichai 310hp
Gear box Fast 9JS150A
Mercedes Benz Technology
10 yeas experiences
North Benz NG80 WEICHAI Engine 290hp EUROIII 6x4 Truck Beiben Tipper Truck Dump Truck
Cabin:
North Benz short cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
Fuel level)
Headlight, Sun protection on cabin.
Engine:
Engine brand: Weichai
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 9.726 liters
Max. Output: 290HP
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/130
Steering: ZJ120D
Brake system:
Double-circulate brake system
Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Benz double Reduction driving axle, Ratio: 1: 5.921(option5.263, 6.733)
Frame: Strengthened frame 300*90*8+6+8
Tyre: 12.00R20
No tyre: 10+1 spare
Spring: 10/13
Fuel tank capacity (L): 300
Tipper Body
Dimension 5600*2300*1500
Capacity :19.32CBM
Thickness of body steel(mm): floor 6 front 6 side & back 4
Hydraulic System --- F type lifting
Cylinder: Φ180x4640
