OBD Vehicle On Board Diagnostics

OBD Engine Status Data Reading

No need for host computer. to have any operation, all data will be return by value.

Precise mileage operation, precise rate can be 99.5%.

Support instant oil consumption,average oil consumption and consumption data output.

Support vehicle failure diagnosing, failure code can be read or clean up by only two commands.



TS-540 OBD Introduction

1.Product introduction

TS-530 is car level gauge product which analyzes the OBDII protocol data. It supports the physical layer of ISO9141-、ISO14230(KWP)、ISO15765(CANBUS), and it can diagnose the ECU communication of most vehicles by connecting with standard OBD-16 interface.

TS-530 OBD converts every sensor data of vehicle electronic control system to UART format, and then output them, which achieved the fast connection between mobile dvr and vehicles.

OBD also supports standard OBDII car failure diagnosing function, supports DTC diagnosing requirements, fault code output and cleaning up.

OBD Vehicle Driving DataOBD Vehicle Driving DataOBD Engine Status Data Reading

2.Product features

  • Support standard OBDII interface.
  • Cover all main car protocols.
  • Double MCU,fast processing speed.
  • No need for host computer. to have any operation, all data will be return by value.
  • Precise mileage operation, precise rate can be 99.5%.
  • Support instant oil consumption,average oil consumption and consumption data output.
  • Support vehicle failure diagnosing, failure code can be read or clean up by only two commands.
  • Support real-time failure code scanning.
  • Support urgent acceleration & slow down etc driving habits stat.
  • modular design, high integration level.
  • Car level gauge anti-disturb design
  • Easy AT command to operate.


3. Compatible protocols

number

Protocol name

Protocol standard

1

ISO9141-2

ISO9141

2

KWP2000_5BPS

ISO14230

3

KWP2000_FAST

4

CANBUS_11B_500K

ISO15765

5

CANBUS_29B_500K

6

CANBUS_11B_250K

7

CANBUS_29B_250K
