Specification:
-
Material: FR4 PCB TG170
-
Layer count: 10 layers
-
Board thickness: 1.6mm
-
Finish copper thickness: 1.0 oz
-
Surface treatment: ENIG ( Immersion Gold ) Au 2U'', VIP+wrap copper plated
-
Application: Industrial control
Our Capability:
Dielectric of inner laye
(min.)
|
0.002" (0.05mm)
|
Thin core thickness (min.)
|
0.004"(0.1mm)(1/1
OZ) (Without copper foil)
|
Base copper thickness of
outer layer(min.)
|
1/2OZ (0.017mm)
1/3 OZ (0.012mm)
|
Base copper thickness of
outer layer(max.)
|
3 OZ (0.105mm)
|
Base copper thickness
of inner layer(min.)
|
1/3 OZ (0.012mm)
|
Base copper thickness of inner layer(max.)
|
3 OZ (0.105mm)
|
Finished board size(max.)
|
20"*24"
(508mm*609mm)
|
Finished board size(min.)
|
2.756"*2.756"
(70mm*70mm)
|
Finished board
thickness(max.)
|
157.48" (4.0mm)
|
Finished board
thickness(min.)
|
2 Layers：0.016"(0.4mm)
4 Layers：0.020"(0.5mm)
6 Layers：0.028"(0.7mm)
8 Layers：0.031"(0.8mm)
|
|
Finished board
thickness tolerance
(board thickness ≥1.0mm)
|
±3mil (±0.076mm)
|
|
Finished board
thickness tolerance
(0.4mm≤ board thickness＜1.0mm)
|
±2mil (±0.05mm)
|
PCB Manufacturing Process Flow:
FAQ:
A. Why choose High Precision
Technology as PCB supplier?
-- High Precision Technology specialises on PCB manufacturing since 2011 with
rich experiences. We mainly use KB & Shengyi Brand laminiate, Rongda &
Taiyo brand oil and strictly compliance to IPC-6012 class 2. In our Hunan new
factory, all procedures are made in-house. The quality and price can be
controlled effectively. If you are still looking for a suitable supplier of PCB
fabrication, contact us, we will supply professional and flexible support.
B. What’s
kind of certificates do you have?
-- We have certificate ISO9001, ISO14001, UL, TS16949 etc.
C. What's
lead time?
-- The lead time can be negotiable to meet your demands.
D. What is
MOQ (Minimum Order Quantity)?
-- There is no MOQ for new PN, sample is welcome.
E. What informations need to be
supplied for quote?
-- Order quantity, Gerber file, PCB specification ( base
material, layer, PCB finished thickness, base copper thickness, surface
treatment, solder mask color, and others if you have )
F. Is the
files for quote or manufacturing safer?
-- Yes, it is safe as we are professional PCB manufacturer and Non-disclosure
agreement can be signed if you need. All documents from customers are never
shared with any third parties.
G. When can
the quotation be supplied?
-- All quotation can be supplied within 24 hours.
More inquiry,welcome to send us email.We will always give you professional service with 24H/7D online support.
