Specification
|
|
Performance Parameters
|
|
Light Sources
|
630nm red LED
|
|
Supported symbologies
|
1D:UPC,EAN, Code128, AIM-128，ISSN,ISBN, Code39,Code39 Full ASCII,Code32,Code11, Code93,Matrix 2 of 5,Interleaved 2 of 5, Industrial 2 of 5,Codebar,MSI-Plessey,PLessey
|
|
ITF-14,ITF-6,GS1-Databar(RSS)
|
|
2D:PDF417,Data Matrix ,QR Code, Hanxin,
|
|
Scan Mode
|
Automatic inductive
|
|
Precision
|
3mil(Code39),7.5mil(Data Matrix),4mil(PDF 417)
|
|
Scan angle
|
Horizontal: 46.1°；Vertical：30.4°
|
|
Optical System
|
|
Visual Indicator
|
640H*480V pixels(Wide VGA)
|
|
Interface
|
Speaker, LED
|
|
Physical Parameters
|
USB-HID,USB-COM,RS232
|
|
Dimensions
|
75mm*71mm*145mm
|
|
Weight
|
302g
|
|
Material
|
ABS+PC
|
|
Cable length
|
2m
|
|
Environmental Parameters
|
|
Operating Temperature
|
0℃ - 50℃
|
|
Storage Temperature
|
-40℃-70℃
|
|
Humidity
|
0% to 95% RH.Non-condensing
|
|
Shock Resistance
|
1.5m drops to concrete
|
|
Electrical Parameters
|
|
Voltage
|
Operating DC5V ±1%
|
|
Current
|
Operating 350mA
|
|
Motion tolerance
|
2.5m/s
|
