| Power supply voltage |
100 to 240 VAC 50/60 Hz |
| Allowable power supply voltage range |
85 to 110% of the power supply voltage |
| Power consumption |
6 VA max. (at maximum load) |
| Input type |
DC voltage/DC current |
| Output type |
Judgment output: Contact |
| Comparative output: OUT1, OUT2 |
| Current measurement input |
Measurement range |
0-20: 0 to 20 mA |
| 4-20: 4 to 20 mA |
| Indication range |
0-20: -2.00 to 22.00 mA |
| 4-20: 2.00 to 22.00 mA |
| Accuracy |
±0.1% FS ±1 digit max. (23±3 ℃) |
| Input impedance |
Approx. 45 Ω |
| Voltage measurement input |
Measurement range |
0-5: 0 to 5 V |
| 1-5: 1 to 5 V |
| 5: ±5 V |
| 10: ±10 V |
| Indication range |
0-5: -0.500 to 5.500 V |
| 1-5: 0.500 to 5.500 V |
| 5: ±5.500 V |
| 10: ±11.000 V |
| Accuracy |
0-5: ±0.1% FS ±1 digit max. (23±3 ℃) |
| 1-5: ±0.1% FS ±1 digit max. (23±3 ℃) |
| 5: ±0.1% FS ±1 digit max. (23±5 ℃) |
| 10: ±0.1% FS ±1 digit max. (23±5 ℃) |
| Input impedance |
1 MΩ min. |
| Judgment output |
Contact output |
2 output (SPST-NO) |
| Rated load: Resistive load: 250 VAC 5 A (cosφ=1)/5 A at 30 VDC, Inductive load: 250 VAC 1 A (cosφ=0.4)/30 VDC 1 A (L/R＝7 ms) |
| Minimum applicable load: 10 mA at 5 VDC (failure level: P Reference value) |
| Life expectancy: 100,000 operations min. (Electrical)/5,000,000 operations min. (Mechanical) |
| Display |
Display method |
Negative LCD (backlit LED) 7-segment digital display |
| Digits |
5 digit (-19999 to 99999) |
| Character height |
14.2 mm (green/red) |
| A/D conversion method |
Double integral method |
| Sampling period |
250 ms |
| Comparative output response time |
750 ms max. |
| Insulation resistance |
Between the entire external terminal and case: 20 MΩ min. (at 500 VDC) |
| Between inputs, outputs, and power supply: 20 MΩ min. (at 500 VDC) |
| Dielectric strength |
Between the entire external terminal and case: 2,000 VAC 1 min |
| Noise immunity |
±1,500 V at power supply terminals in normal or common mode (waveform with 1-ns rising edge and pulse width of 1 µs/100 ns) |
| Vibration resistance |
Malfunction: 10 to 55 Hz, Single amplitude 0.35 mm, 10 sweeps of 5 min each in X, Y, and Z directions |
| Shock resistance |
Malfunction: 100 m/s2, 3 times each in 3 axes 6 directions |
| Degree of protection |
Front: NEMA TYPE 4X for indoor use (equivalent to IP66) |
| Case rear: IP20 |
| Terminals: IP00 + finger protection (VDE0106/100) with terminal Cover |
| Memory protection |
Non-volatile memory (Number of rewrites: 100,000) |
| Ambient temperature |
Operating: -10 to 55 ℃ (with no freezing or condensation) |
| Storage: -25 to 65 ℃ (with no freezing or condensation) |
| Ambient humidity |
Operating: 25 to 85 % (with no condensation) |
| Accessories |
Waterproof packing, Terminal Cover, Unit label |
| Weight |
Approx. 200 g |
