Original HBA card 4350-16i

4350-16i SAS/SATA 12Gb HBA
Model 4350-16i
Lifecycle Active
Description SAS/SATA
Part number
 4Y37A72481
Warranty 3 Years

Facebook Twitter Pinterest LinkedIn 分享
4350-16i SAS/SATA 12Gb HBA PCIe 3.0 x8
Applications
The 4350 SAS/SATA HBA Series delivers enterprise resiliency with its broadly deployed Smart Storage stack. Based on the Adaptec PM8222 8x12G SmartIOC 2100 SAS/SATA protocol controller, the 4350 HBAs provide a robust and stable solution that can handle the toughest system workloads and configurations. The adapters offers over 40% power savings compared to previous generations, and significant power advantages versus competing solutions.
Key Features
  • PCIe 3.0 x8 host interface
  • 12 Gbps SAS/SATA host bus adapter, based on the Adaptec HBA 1100-8i and 1100-16i
  • PCI low profile, half-length form factor
  • 8 or 16 internal 12 Gbps SAS/SATA ports
  • 4350-8i support connectivity to 8 internal drives
  • 4350-16i support connectivity to 16 internal drives
  • Up to 12 Gbps throughput per port
  • Supports 12, 6, or 3 Gbps SAS speeds
  • Supports 6 or 3 Gbps SATA speeds
  • Two internal x4 HD Mini-SAS connectors (SFF-8643)
  • Non-RAID (JBOD mode, known as “raw” or "HBA mode” in Adaptec parlance) support for SAS and SATA HDDs and SSDs (RAID not supported)
  • Optimized for SSD performance
  • High performance architecture with a queue depth of up to 1014
  • Advanced power management support
Specification
Model 4350-16i
Form factor PCIe low profile
Adaptec equivalent Adaptec HBA 1100-16i
Host Connector PCIe 3.0 x8
Port interface 12 Gb SAS
Number of ports 16
Port connectors
 4x Mini-SAS HD x4 (SFF-8643)
Drive interface
 SAS, SATA

Lead time

Quantity (pieces) 1-10 10-60 >60
Lead time (days) 3 3-5 To be negotiated
