OSX001002 Overview
Huawei OSX001002 is SFP+ Double Fiber Transceiver supporting 1.25-10.31 Gbps data rate in 10 km distance over Single-Mode Fiber (SMF).
Brand Name: Huawei
Product Number: OSX001002
Discription: Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2~0.5dBm,-12.6dBm,LC,SM,10km)
|
Media Type:
|
Single-Mode
Fiber (SMF)
|
|
TX Wavelength:
|
1310 nm.
|
|
RX Wavelenght:
|
1310 nm.
|
|
Minimum Optical Budget:
|
6 dB
|
|
Maximum Distance:
|
10km
|
|
Supported Data Rate:
|
1.25-10.31Gbps
|
|
Supported Applications:
|
10G Ethernet (10.31Gbps), Gigabit
Ethernet (1.25 Gbps), STM-64 (9.95Gbps)
|
|
DDM/DOM:
|
Support
|
|
Temperature Range:
|
Standard 0°-70°C
|
|
Connectors:
|
Double LC
|
|
Tx Wavelength Bandwidth:
|
100 nm
(1260-1360 nm)
|
|
Rx Wavelength Bandwidth:
|
100 nm
(1260-1360 nm)
|
|
Minimum Transmitting Power:
|
-8 dB
|
|
Maximum Transmitting Power:
|
-0.5 dB
|
|
Receiver Sensitivity:
|
-14 dBm
|
|
Receiver Overload:
|
0.5 dBm
|
|
Dispersion:
|
70-100 ps/nm
|
|
Transmitter Type:
|
DFB Laser
|
|
Receiver Type:
|
PIN photodiode
|
|
Power:
|
+3.3V single
power supply
|
|
Chipset:
|
MAXIM, MINDSPEED, SEMTECH
|
|
Compliance:
|
CE, Class 1 FDA and
IEC60825-1 Laser Safety Compliant, SFF-8431, RoHS, SFP MSA
|
|
Transceiver Type:
|
SFP+
|
