P10 outdoor full color advertising led screens suppliers

It supports different languages, like French, Spanish, English, Russian, Polish, Italian, and so on.High luminance reaches to 4500 CD/sq.m. Automatic brightness adjustment could be realized by adding sensor.

Facebook Twitter Pinterest LinkedIn 分享


  • Parameter

    P10 Outdoor LED Die-casting Cabinet

    Module

    Pixel Configuration

    SMD3535

    Pixel Pitch

    10.0mm

    Module Resolution(W×H)

    32×16

    Module Size(mm)

    320×160

    Weight Per Module

    0.52kg

    Max Power Consumption

    30W

    Cabinet(Panel)

    Modue Qty Per Cabinet(W×H)

    263x87cm(91x34 inches)

    Cabinet Resolution(W×H)

    256x80dot

    Area per Cabinet(㎡)

    0.6144

    Weight (Kg)

    132kgs

    Pixel Density(pixel/㎡)

    10000

    Cabinet Flatness(mm)

    ≤0.2

    Cabinet Material

    Aluminum frame

    Optical Parameters

    Brightness Calibration by Per Dot

    Yes

    White Balance Brightness(nits)

    ≥4000

    Color Temperature

    3200--9300 deg. K (adjustable)

    View Angle

    Horizontal 110°；Vertical 80°

    Brightness Uniformity

    ≥97%

    Max.Contrast

    4000:1

    Electrical Parameters


    Max Power Consumption(㎡)

    360W/㎡

    Average Power Consumption(㎡)

    280W/㎡

    Input Voltage(VAC)

    110 ± 20% or to 220 ± 20%

    Processing Performance

    Driving Mode

    1/4 scan

    Frame Rate(Hz)

    50 to 60

    Refresh Frequency(Hz)

    ≥800

    Using Parameters

    Best Viewing Distance(m)

    3-60m

    Lifetime(Hours)

    ≥100,000

    Working Temperature(℃)

    -20 ~ + 45

    Stored Temperature(℃)

    -30 ~ + 60

    Working Humidity(RH)

    10 — 90%(no dew formation)

    Stored Humidity(RH)

    10 — 95%(no dew formation)

    Waterproof

    Yes

    Protection Grade

    IP45



1)High definition and high brightness;
2)Long durability and high reliability;
3)Advance video control system and Super input system;
4)Low maintenance cost ;
5)Vividly display;
6)Wide viewing angle;
7)Easy installation and maintenance;

Warranty

1.We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.

2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in factory.

3.After warranty , we also can offer you the parts for replacement at our bottom price.

4.After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it

and offer you a good solution to solve the problem.

5.We also could solve problems for you until it recovers well by remote control!




Delivery Time:

1.Delivery time: Accomplish manufacturing within 7 days after receiving the deposit.
2.Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of
3.The display to confirm it is Ok for delivery.
