Printing Method

Thermal Line

Resolution

8 dots/mm, 384 dots/line

Effective Printing Width

48mm

Printing Speed

50-80mm/s

Character Set

ASCII, GB18030(Chinese), BIG5

Print Font

ANK: 12 x24, 9 x24 Chinese: 24 x 24

Self-defined Character

Yes

Barcodes

EAN-13, EAN-8, UPC-A, UPC-E, CODE39,
CODE93, CODE128, CODABAR, INTERLEAVED 25

Driver

Windows XP/Windows Vista/Windows 7/IOS/Linux

Graphic

Support bitmap downloading

Paper End Sensor

Yes

Overheating Protection

Yes

Black Mark Location

Yes

Auto Sleeping

Yes

Interface

USB + Bluetooth

Battery

DC7.4V,1.5A rechargeable Li-ion battery

Charger

DC9V/2A

Printer head life

50km

Paper Type

Thermal paper

Paper Width

57.5± 0.5mm

Paper Thickness

0.06 to 0.08mm

Paper Roll Diameter

40mm (Max.)

Paper Supply Method

Drop-in Easy loading

Paper Cutting Method

Manual

Operating Temp/Humidity

0-50°C/10%-80%

Storage Temp/Humidity

-20-60°C / 10%-90%

Dimension (L x W x H)

105 x 75 x48mm

Weight

235g
