Model No.:
|
YX-P6
|
|
Pixel pitch:
|
6mm
|
|
LED encapsulation:
|
SMD3528
|
|
Resolution:
|
27777dots/m2
|
|
Brightness:
|
≥1300nit
|
|
Cabinet size:
|
576*576*106mm
|
|
Cabinet weight:
|
9kg
|
|
Average powe consumption:
|
≤600w/m2
|
|
Best viewing angle:
|
H:160° V:120°
|
|
Refresh rate:
|
360-4800Hz
|
|
Grey scale:
|
14-16bit
|
|
Best viewing distance:
|
1.5-50m
|
|
Protection Level:
|
IP20
|
|
Cabinet Material:
|
Die-casting Aluminum
|
|
Operating Voltage:
|
AC220V/50Hz,110v/60hz
|
Quick Detail:
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect
4) Big viewing angle to 140 degree at horizontal line,140 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair
Indoor full color LED display could be used in indoor environment such as municipal mansion, enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD encapsulation technology, its purpose is to play the important news or events or TV program etc.
Features of the product:
1) Super-thin and light cabinet can save room and time of installation.
2) High and adjustable brightness can meet the demands of the changing requirement of
customer in different environments.
3) No mosaic due to excellent flatness and nice uniformity of light-emitting
4) Wide viewing angles and the horizontal angle can reach 140° the images effect will not
change largely in the range.
5) High density make the images softer and vivider
6) Single-lamp maintenance with low cost.
7) Good heat dissipation capability because of the unique design of vent fan
8) Environmental-friendly and energy-saving.
9).Technical Data of P6 Indoor LED Display full color:
Warranty:
1.We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty , we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you until it recovers well by remote control!
