#PC - Mabor Cupel Gold Assay Smelting Refining Melting Cupels
Cupel design:
|
CUPEL DIMENSION DATA
|
|
Size
|
Outer
Dia
|
Dia of
Cup
|
Dia of
Bottom
|
Height of
Cupel
|
Width of
Cup
|
Weight
(Approx)
|
|
PC
|
D
|
D1
|
D2
|
H
|
H1
|
(grams)
|
|
mm
|
254
|
184.7
|
203.2
|
161.64
|
55.42
|
16000
|
|
inch
|
10.0"
|
7.27"
|
8.00"
|
6.36"
|
2.18"
|
16000
|
Feature: Each cupel is 10" diameter by 6" tall and will absorb 14,000 grams of lead.
The lead button for cupellation is typically generated in the crucible fusion from the fire assay process, but can also be produced by a scorification assay, or a bullion assay where the precious metal is wrapped in lead foil.
More demensions of the crucibles for melting gold we have are as follows:
|
Size
|
D (mm)
|
D1 (mm)
|
D2 (mm)
|
B/R
|
H (mm)
|
H1 (mm)
|
H2 (mm)
|
|
CS-6A
|
40.0
|
32.7
|
30.0
|
3.7
|
25.4
|
12.3
|
6.0
|
|
CS-6C
|
40.2
|
30.3
|
30.5
|
5.0
|
27.5
|
8.0
|
9.0
|
|
CS-6D
|
38.8
|
32.8
|
30.0
|
3.0
|
30.0
|
7.8
|
9.5
|
|
CS-7A
|
39.7
|
31.2
|
30.0
|
4.3
|
28.5
|
11.8
|
9.0
|
|
CS-7AL
|
39.7
|
31.2
|
30.0
|
4.3
|
28.5
|
12.3
|
6.0
|
|
CS-7AS
|
40.0
|
31.0
|
30.0
|
4.5
|
34.0
|
14.0
|
12.0
|
|
CS-7B
|
39.7
|
31.2
|
30.0
|
4.3
|
32.0
|
11.8
|
12.5
|
|
CS-7C
|
40.0
|
33.0
|
30.0
|
3.5
|
30.0
|
9.5
|
4.0
|
|
CS-8
|
44.3
|
34.2
|
34.6
|
5.1
|
27.1
|
8.5
|
9.0
|
|
CS-8A
|
45.3
|
38.0
|
36.9
|
3.7
|
35.0
|
12.5
|
13.0
|
|
CS-9
|
51.0
|
40.0
|
42.1
|
5.5
|
29.0
|
10.5
|
9.0
|
|
CS-10
|
60.0
|
52.6
|
49.7
|
3.7
|
30.2
|
11.5
|
11.0
|
|
CS-11
|
56.8
|
47.8
|
48.8
|
4.5
|
44.0
|
14.8
|
10.0
|
|
CS-12
|
80.2
|
57.5
|
62.5
|
11.4
|
47.0
|
16.5
|
11.0
|
|
CS-14
|
110.0
|
80.0
|
88.0
|
15.0
|
70.0
|
24.0
|
14.0
|
|
CS-PC
|
254.0
|
184.7
|
203.2
|
34.7
|
161.6
|
55.0
|
32.3
|
More information, please contact us freely. info@csceramic.com
