1、Up to 80% Energy-saving, mercury-free and 100% recyclable, energy saving and environmental protection
2、Constant current internal driver, safety guaranteed
3、High PF value over 0.9 for decrease of electricity loss
4、High quality PCB for good heat dissipation
5、High light efficacy, cost effective
6、No flicker,no delay, Instant on/off
7、Direct replacement for T8 fluorescent tubes is used to quick and easy installation to minimize retrofit and maintenance costs
8、Widely used in factories, car parks, supermarkets, offices and other public places is best retrofit for Philips, Osram, Panasonic T8 fluorescent lamp



Model	Size (mm)	Watt	Input Voltage	SMD LED	Material	PF	CRI	Cap	Beam Angle	Light efficiency
T8-60CM-10W-S	φ26*588	10w	AC85-265V	SMD2835	Half aviation Aluminum+ PC cover	>0.92	>80	G13 & G5,rotatable cap optional	140°	100LM/W or more higher
T8-120CM-18W-S	φ26*1198	18w	AC85-265V	SMD2835	Half aviation Aluminum+ PC cover	>0.92	>80	G13 & G5,rotatable cap optional	140°	100LM/W or more higher
T8-150CM-25W-S	φ26*1498	23w	AC85-265V	SMD2835	Half aviation Aluminum+ PC cover	>0.92	>80	G13 & G5,rotatable cap optional	140°	100LM/W or more higher





Warning: Switch off power supply BEFORE COMMENCING WORK!

Step1. Remove the fluorescent lamp.

Step2. Cut off all wires which connected to inductive ballast or electrical ballast.

Step3. Install LED tube into lighting fixture with below one(Type I or Type II) wiring method refer to  the label on the tube.



Step 4.Switch on power.



Perfect used for Parking lot, Corridor, Factory, Office, Shopping mall and Hotel lighting etc
