Basic Info
Place of Origin:Hefei,China
Product category:Volumetric rotary piston water meter
Model Number:LXHP-15A~40A Volumetric piston water meter
Keyword:
Volumetric Rotary Piston plastic or brass Class C water meter
Type:Volumetric Rotary Piston water meter
material:brass
standard:ISO4064 class C
advantage:Removable,easy to fix
Max temperature:40℃ (cold)
Nominal Pressure:10bar
pressure loss:63
Certificate:ISO9001/ISO14001/OHSAS1800
Material
Plastic/Nylon/ fiberglass reinforced polymerization amine
Body, with plastic accessories
APPLICATION
Measuring the volume of cold potable water passing through the pipeline
Size
DN15 to DN40 for cold water meter
FEATURES
OEM Acceptable
Sealed dry dial register ensures clear reading.
Pole ring magnet polymer coating as protection against deposits.
Magnetic drive , lower transimission resistance.
Inside calibration device.
Internal strainer, inlet strainer are optional
Large measuring range high flow accuracy.
Steady curve characteristics.
Measuring accuracy is up to iso4064, class b.
Low starting flow rate and excellent metrological performance.
Fiberglass reinforced polymerization amine,corrosion resistance.
Ensures high sensitivity and accurate registration throughout a wide flow range
Both brass thread connections and plastic thread connections are available
WORKING CONDITION
1.Water temperature: ≤50℃
2.Water pressure: ≤ 10bar (16 bar on request)
EMI Water Meter offer you:
Volumetric Rotary Piston tap brass Class C water meter
Factory direct price
Nice quality
Quick shipping
No limit for MOQ, trial order is welcome
After sales services 7*24
Warranty: 24 months
15 patented product
Support OEM according to your requirements
