ITEM
NO.
|
DESCRIPTION
|
UNIT
|
SPECIFICATION
|
SPECIFICATION
|
|
01
|
Control system type
|
/
|
PLC/
Servo
|
PLC/
Servo
|
|
02
|
Cutting length
|
mm
|
2440-2460
|
1830-2460(adjustable)
|
|
03
|
Cutting width
|
mm
|
1220-1240
|
900-1240(adjustable)
|
|
04
|
Cutting
thickness
|
mm
|
10-60
|
10-60
|
|
05
|
Saw
blade size
|
mm
|
Φ180/φ305
|
Φ180/φ305
|
|
06
|
Vertical
sawing speed
|
m/min
|
30-60m/min
|
30-60m/min
|
|
07
|
Horizontal sawing speed
|
m/min
|
30-60m/min
|
30-60m/min
|
|
08
|
Motor power
|
kw
|
37
|
37
|
|
09
|
Application
|
/
|
Plywood,
MDF, Particle board etc.
|
Plywood,
MDF, Particle board etc.
|
|
10
|
Working style
|
/
|
Infrared
ray guidance
|
Infrared
ray guidance
|
|
11
|
Weight
|
kg
|
5000kg
|
5000kg
|
|
12
|
Feeding way
|
/
|
Manual/Full
automatic
|
Manual/Full
automatic
|
Features
1. The
machine frame and rail is produced by planning machine, which guarantee the
accuracy of the machine.
2. Automatic
lifting pusher and transfer platform increase the output of plywood trimming.
3. Double
saw blade of saw head will prevent burrs on the board edge area.
4. The
wide saw design technology prevents dust and improves the service lift of the
cylindrical guide.
