Popular in Africa Factory heavy duty truck 6x4 dump truck beiben dump truck

Wheel base  (mm)

3800+1450

Curb weight kg

12260

Upper body Dimension(Lx W x H)

5800×2300×1500      sand body

Engine

Model

WP10.340E32,water-cooled,four strokes,6 cylinders straight in line,turbocharged

Power, max   kw/rpm

250/2200

Max torque(Nm/rpm)

1350/1100-1600

Emission

EURO

Fuel tanker capacity L

300

Clutch

Model

GFX420, Single dry frictional disc,Hydraulic boosting

Gearbox

Model

RT11509C(With 9 forward gears,1 reverse gear)

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame

Fish belly shape, variable width, variable sections

Front axle (Mercedes Benz  Technology

Double-shoe pneumatic brake, non-driving steering axle

Middle and Rear axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle

Tyre

12.00R20

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Short cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure.Can be tipped forwardly; Inner A/C
