Powered by 6LTAA Series Engine

1. Powered by brand new original Cummins water-cooled diesel engine.

2. Alternator options: Brand new STAMFORD, LEROY SOMER, or Hosem single bearing 3 phase alternator with IP23 and H insulation class.

3. Copper 40ºC radiator with the engine-driven fan mounted on the skid.

4. Delixi or Chint branded case circuit breaker mounted.

5. Heavy-duty fabricated steel-based frame with built-in fuel tank for at least 8 hours of continuous running.

6. Complete set mounted on a based frame with anti-vibration mountings.

7. Industrial 9 dB muffler exhaust system with flexible connects and bellows.

8. Based frame with fuel, oil, and coolant drain cocks for easy maintenance.

9. 12/24V DC electric start system with free maintenance battery & smarten brand battery charger.

10. Set mounted automatic control panel, with SMARTGEN or Deepsea and ComAp controller module with AMF function for automatic start & stop.

11. Document supply: test report of the generator, set of drawings, and manuals.



Model Standby Power  Prime Power Engine Model Dimension Silent Type Weight Datasheet
kVA kW kVA kW LXWXH(MM) KG
A-C22-1 22 18 20 16 4B3.9-G1 2300x 900x1250 765 Download
A-C22-2 22 18 20 16 4B3.9-G2 2300x 900x1250 765 Download
A-C28-1 28 22 25 20 4B3.9-G1 2300x 900x1250 765 Download
A-C28-2 28 22 25 20 4B3.9-G2 2300x 900x1250 765 Download
A-C44-1 44 35 40 32 4BT3.9-G1 2300x 900x1250 770 Download
A-C44-2 44 35 40 32 4BT3.9-G2 2300x 900x1250 770 Download
A-C55 50 40 55 50 4BT3.9-G2 2300x 900x1250 780 Download
A-C60 60 50 55 45 4BTA3.9-G2 2450x900x1250 824 Download
A-C72 72 57 65 52 4BTA3.9-G2 2450x900x1250 824 Download
A-C88 88 70 80 63 4BTA3.9-G11 2450x900x1250 980 Download
A-C100 100 77 90 70 QSB3.9-G3 2450x900x1250 980 Download
A-C110-1 110 88 100 80 6BT5.9-G1 2900×1080×1500 1150 Download
A-C110-2 110 88 100 80 6BT5.9-G2 2900×1080×1500 1185 Download
A-C121 121 96 110 87 6BT5.9-G2 2900×1080×1500 1185 Download
A-C138 138 110 125 100 6BTA5.9-G2 2900×1080×1500 1280 Download
A-C150-1 150 119 136 109 QSB5.9-G3 3200×1080×1500 1350 Download
A-C150-2 150 119 136 109 6BTAA5.9-G2 3200×1080×1500 1280 Download
A-C175 175 140 160 127 6BTAA5.9-G12 3200×1080×1500 1300 Download
A-C203-1 203 163 185 148 6CTA8.3-G1 3200×1080×1500 1600 Download
A-C203-2 203 163 185 148 6CTA8.3-G2 3200×1080×1500 1550 Download
A-C210 210 167 190 152 QSB6.7-G4 3500×1126×1700 1550 Download
A-C220 220 176 200 160 6CTAA8.3-G2 3500×1126×1700 1700 Download
A-C275-1 275 220 250 200 MTA11-G2A 3900×1300×1900 2750 Download
A-C275-2 275 220 250 200 MTA11-G2 3900×1300×1900 2750 Download
A-C275-3 275 220 250 200 NTA855-G1 3900×1300×1900 3010 Download
A-C275-4 275 220 250 200 6LTAA8.9-G2 3500×1126×1700 1900 Download
A-C286 286 229 260 208 6LTAA8.9-G3 3500×1126×1700 2500 Download
A-C290 290 232 260 208 QSL8.9-G4 3500×1126×1700 1900 Download
A-C300 300 240 275 220 NTA855-G1A 3900×1300×1900 3010 Download
A-C312 312 250 284 227 6LTAA9.5-G3 3500×1126×1700 2500 Download
A-C344-1 344 275 313 250 MTAA11-G3 3900×1300×1900 2750 Download
A-C344-2 344 275 313 250 NTA855-G1B 3900×1300×1900 2900 Download
A-C344-3 344 275 313 250 NTA855-G2 3900×1300×1900 2900 Download
A-C344-4 344 275 313 250 6LTAA9.5-G1 3500×1126×1700 2750 Download
A-C378 378 302 343 275 NTA855-G2A 3900×1300×1900 2950 Download
A-C385 385 308 350 280 NTA855-G4 3900×1300×1900 3000 Download
A-C408 408 326 370 296 QSZ13-G6 3420×1150×2190 3140 Download
A-C413-1 413 330 375 300 NTAA855-G7 3900×1300×1900 2800 Download
A-C413-2 413 330 375 300 KTA19-G2 3580×1277×2065 3950 Download
A-C424-1 424 340 385 310 6ZTAA13-G3 4350×1450×2180 3220 Download
A-C424-2 424 340 385 310 6ZTAA13-G3 4350×1450×2180 3220 Download
A-C450 450 360 N/A N/A NTAA855-G7A 3000×1050×1780 2900 Download
A-C456 456 365 415 332 QSZ13-G7 3420×1150×2190 3140 Download
A-C484 484 387 440 352 6ZTAA13-G2 4350×1450×2180 3220 Download
A-C495-1 495 396 450 360 KTA19-G3 4700×1800×2380 2900 Download
A-C495-2 495 396 450 360 6ZTAA13-G4 4350×1450×2180 3220 Download
A-C495-3 495 396 450 360 QSZ13-G2 4700×1800×2380 3220 Download
A-C511 511 409 465 372 QSZ13-G5 4700×1800×2380 3220 Download
A-C550-1 550 440 500 400 KTA19-G3A 4700×1800×2380 4250 Download
A-C550-2 550 440 500 400 KTA19-G4 4700×1800×2380 4300 Download
A-C560 560 448 510 408 QSZ13-G3 4700×1800×2380 3220 Download
A-C575 575 462 525 420 KTAA19-G5 4700×1800×2380 4550 Download
A-C633 633 506 575 460 KTAA19-G6 4700×1800×2380 4550 Download
A-C650 650 520 N/A N/A KTA19-G8 4700×1800×2380 4550 Download
A-C688-1 688 550 N/A N/A KTAA19-G6A 4700×1800×2380 4700 Download
A-C688-2 687 550 625 500 KT38-G 6050×2438×2591 6000 Download
A-C784 784 627 713 570 KTA38-G1 6050×2438×2591 6150 Download
A-C800 800 640 725 580 KT38-GA 6050×2438×2591 6400 Download
A-C825 825 660 750 600 KTA38-G2 6050×2438×2591 6600 Download
A-C880 880 704 800 640 KTA38-G2B 6050×2438×2591 6700 Download
A-C1000 1000 800 910 728 KTA38-G2A 6050×2438×2591 6850 Download
A-C1100 1100 880 1000 800 KTA38-G5 6050×2438×2591 7150 Download
A-C1250 1250 1000 N/A N/A KTA38-G9 6050×2438×2591 7250 Download
A-C1375 1375 1100 1250 1000 KTA50-G3 12192×2438×2591 9140 Download
A-C1513 1513 1210 1375 1100 KTA50-G8 12192×2438×2591 9400 Download
A-C1650 1650 1320 1500 1200 KTA50-GS8 12192×2438×2591 9600 Download
