Specification

LIGHT SOURCE

Lamp: 18pcs*10W 4in1/5in1/6in1 LED

Lifespan: 50,000H

OPTICS

Lens size:  29mm

Beam angle:  25 °/45 °/60 °

COLORS

4in1/5in1/6in1 LED linear color mixing

FEATURES

Dimmer:  0-100% linear electronic dimmer

Dimmer mode: 4 dimmer modes

Strobe: 1-20Hz or random

Protocol RDM compatible

LED controlled in indepent groups

Perfect pulse and rainbow effect

Smooth color mixing

DISPLAY

Green backgroud LCD screen

15 second standby auto lock

SOFTWARE

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 6/8/11/3 CH

OTHER SPEC

Constant current driver

32bit MCU with ARM cortex

Working temperature monitoring

Over-temperature protection

Intelligent cooling system

LED display menu on/off

Built-in auto and fade program

Body Material: Aluminum Die-casting

IP65 AC power in/out cable for IP65

IP65 3-pin DMX in/out cable for IP65

POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 200W@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 22x28x32cm

Packing dimension:

                         59x30x35cm(2 in 1 Carton)

                         70x60x45cm(6 in 1 flightcase)

Net Weight:         4.5kg

Gross Weight:

                         12kg(2 in 1 Carton)

                         50kg(4 in 1 flightcase)
