Professional Radio 3W UHF 400-470MHz PTT walkie talkie
3W Professional 3KM UHF PTT Walkie Talkie,highlights small size, wide band coverage, stable output power and clear audio quality, which perfectly meets the most practical needs required by commercial application.
Quick Details
1.Frequency Range: 136-174MHz/400-480MHz
2.16 Memory Channels
3.Output Power: 3W
4.Scan
5.PC Software Programmable, Encrypted Programming Software
6.VOX Function
7.CTCSS/DCS
8.Chinese and English Voice Prompt
9.Power Saving Function, Low Power Warning
10.High/Low Power Selective
11.Wide/Narrow Bandwidth Selective
12.Emergency Alarm
13.Monitor, Reverse Frequency
14.Busy Channel Lock
15.Transmitter Time-out Timer(TOT)
16.Side Key Assignment
17.0-9 Grades Squelch Level Setting
18.ANI and DTMF Function
19.2-tone
20.Remote Kill , Stun, Activate & Reviv
Specification
|
GENERAL
|
|
Frequency
Range
|
136-174MHz/400-480MHz
|
|
Operating
Temperature
|
-20℃to +55℃
|
|
Frequency
Combination
|
please
lock frequency synthesize
|
|
Frequency
Stability
|
±2.5ppm
|
|
Memory
Channel
|
16
|
|
Working
voltage
|
3.6V
|
|
Antenna
Impedance
|
50Ω
|
|
Operating
Mode
|
simplex
of co-frequency or alien
|
|
Dimensions
|
85*38*25mm
|
|
Weight
|
105g
|
|
TRANSMIT PART
|
|
RF
power
|
3W/1W
|
|
Modulate
Mode
|
F3E
|
|
Max.Freq.Deviation
|
≤5KHz
|
|
Remain
Wave Radiation
|
＜-60dB
|
|
Transmitting
Current
|
≤1000mA
|
|
RECEIVER PART
|
|
Sensitivity
|
＜0.20uV (12dB SINAD)
|
|
Squeich
Sensitivity
|
＜0.20uV
|
|
Intermodulation
Antijamming
|
50dB
|
|
Audio
Power output
|
500mW
|
|
Receiving
Current
|
≤100mA
|
|
Squelch
Stangby
|
20mA
|
3W Professional 3KM UHF PTT Walkie Talkie
Service
Package: Each package in gift box; 20PCS in strong carton
Payment: Paypal, Western Union, T/T, LC
Lead time: Sample: 1-3 working days
Wholesales order: 500PCS within in 5-7 days
OEM order: 7-15 days after receiving your deposit and confirm sample package design.
Shipping
Express: door to door service DHL,UPS, FEDEX, TNT and so on.
By air: To destination airport, need to assist clear customs, without door to door service.
By sea: To destination port, need to assist clear customs, without door to door service.
The shipping cost depends on weight and dimension, will recommend the cheapest and safest way according your detail quantity.
Shipping period depend on your location. If deliver by express, it take 3-7 days from China to destination country. Some remote need more 1-3 days.
