Cisco PWR-C1-1100WAC overview
Cisco 3850 Series Power Supply - PWR-C1-1100WAC 1100W AC Config 1 Power Supply for 3850 Series.
● Integrated wireless controller capability with:
◦ Up to 40G of wireless capacity per switch (48-port RJ45 models)
◦ Support for up to 100 access points and 2000 wireless clients on each switching entity (switch or stack)
● 24 and 48 10/100/1000Mbps data PoE+ and Cisco UPOE models with Energy-Efficient Ethernet (EEE)
● 24 and 48 100Mbps/1/2.5/5/10 Gbps Cisco UPOE models with Energy-Efficient Ethernet (EEE)
● 12- and 24-port 1 Gigabit Ethernet SFP-based models
● 12- and 24-port 1/10 Gigabit Ethernet SFP+-based models
● 48-port 1/10 Gigabit Ethernet SFP+ model with 4 fixed 40 Gigabit Ethernet QSFP+ uplinks
● Cisco StackWise-480 technology provides scalability and resiliency with 480 Gbps of stack throughput
● Cisco StackPower® technology provides power stacking among stack members for power redundancy1
● Five optional uplink modules with 4 x Gigabit Ethernet, 2 x 10 Gigabit Ethernet, 4 x 10 Gigabit Ethernet, 8 x 10 Gigabit Ethernet4, or 2 x 40 Gigabit Ethernet QSFP+ ports
● Dual redundant, modular power supplies and three modular fans providing redundancy
● Full IEEE 802.3at (PoE+) with 30W power on all copper ports in 1 Rack Unit (RU) form factor
● Cisco UPOE with 60W power per port in 1 Rack Unit (RU) form factor
● IEEE 802.3bz (2.5/5 G/s BASE-T) to go beyond 1 Gb/s with existing Cat5e and Cat6
● IEEE 802.1ba AV Bridging (AVB) built-in to provide better AV experience for including improved time synchronization and QoS
● Software support for IPv4 and IPv6 routing, multicast routing, modular Quality of Service (QoS), Flexible NetFlow (FNF), and enhanced security features
● Single universal Cisco IOS® Software image across all license levels, providing an easy upgrade path for software features
● Cisco DNA services delivered through Cisco ONE™ Software, providing simplified, high-value solutions with license portability and flexibility
● Support for AES-256 with the powerful MACSEC 256-bit for SFP+ and Multigigabit models and 128-bit encryption algorithm available on all models
● Enhanced Limited Lifetime Warranty (E-LLW) with Next Business Day (NBD) advance hardware replacement and 90-day access to Cisco Technical Assistance Center (TAC) support
Specification
|
Power supply rated maximum
|
1100W
|
|
Total output BTU (Note: 1000 BTU/hr = 293W)
|
3793 BTU/hr, 1100W
|
|
Input-voltage range and frequency
|
115-240VAC,
50-60 Hz
|
|
Input current
|
12-6A
|
|
Output ratings
|
-56V at 19.64A
|
|
Output holdup time
|
10 ms minimum at 102.5VAC
|
|
Power-supply input receptacles
|
IEC 320-C16
(IEC60320-C16)
|
|
Power cord rating
|
13A
|
|
Physical specifications
|
(H x W x D): 1.58 X 3.25 X 13.7 in
Weight: 3 lb
(1.4 kg)
|
|
Operating temperature
|
23 to 113°F (-5 to 45°C)
|
|
Storage temperature
|
-40 to 158°F (-40 to 70°C)
|
|
Relative humidity operating and nonoperating noncondensing
|
5 to 90% noncondensing
|
|
Altitude
|
10,000 ft. (3000 meters), up to 45°C
|
|
MTBF
|
Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
|
|
EMI and EMC compliance
|
FCC Part 15 (CFR 47) Class A
ICES-003 Class A
EN 55022 Class A
CISPR 22 Class A
AS/NZS 3548 Class A
BSMI Class A (AC input models only)
VCCI Class A
EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
|
|
Safety compliance
|
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
|
|
LED indicators
|
“AC OK”: Input power to the power supply is OK
“PS OK”: Output power from the power supply is OK
|
