QTZ63(5211) Fixed and Mobile Costruction Building Tower Crane
Quick Details
1.6t max load, 52m working radius with tip load 1.1t.
2. hydraulic lifting tower crane/hammed head topkit construction tower crane/building tower crane
3. China-made high quality tower crane, China good tower crane manufacturers with best price
4. high efficiency, CE approved, ISO and GOST certification, oversea service available
It can be fixed tower crane type, mobile tower crane or rail-mounted tower crane type.
Safety devices: 1): hoist height limit 2): over speed limit 3) over load limit 4):lifting moment limit 5): slewing angle limit 6): emergency stop button 7):obstruction light (tip of jib, tower head) 8): wind lock device.
Main technical parameters of the tower crane:
| Model
|
QTZ63(5211)
|
| Jib Length (M)
|
52
|
| Basic Height (M)
|
40
|
| Max. Possible Height (M)
|
161
|
| Max. Load (T)
|
6
|
| Tip Load (T)
|
1.1
|
| Main Material (mm)
|
160×160×14 angle steel
|
| Mast Section Dimension (m)
|
1.615×1.615 ×2.5
|
| Hoisting Speed (a=2)m/min
|
80/40/10
|
| Slewing Speed (r/min)
|
40/20
|
| Radius-changing Speed (m/min)
|
22/33
|
| Jacking-up Speed (m/min)
|
0.6
|
| Total Motor Power (kw)
|
32.8
|
| Weight of Independent Structure (kg)
|
33279
|
| Counter weight (T)
|
11.5
|
| Base Form
|
Built-in Type
|
Our Service
As a professional exporter,our target is to serve worldwide clients with high-quality products, great-reliability, devoted responsibility,professional services and honorable credibility to meet customers’ requirements in all aspects. We will supply you 24 hours a day and 7 days a week after-sale services.
If you want to know more about our products, pls contact us by email or phone. Also welcome consult us any question at your convenience, any inquiry or kind suggestions from you will be very appreciated.
Looking forward your kindly inquiry and hope to help your strong business in near future!
