Media Type:

Single-Mode Fiber (SMF)

TX Wavelength:

1310 nm.

RX Wavelenght:

1310 nm.

Minimum Optical Budget:

6 dB

Maximum Distance:

10km

Supported Data Rate:

1.228-10.138 Gbps

Supported Applications:

CPRI option 2 (1228.8 Mbps), CPRI option 3 (2.458 Gbps), CPRI option 5 (4.915 Gbps), CPRI option 6 (6.144 Gbps), CPRI option 7 (9.830 Gbps), CPRI option 8 (10.138 Gbps), OBSAI RP3 x 2 (1.536 Gbps), OBSAI RP3 x 4 (3.072 Gbps), OBSAI RP3 x 8 (6.144 Gbps)

DDM/DOM:

Support

Temperature Range:

Industrial -40°C – +85°C

Connectors:

Double LC

Tx Wavelength Bandwidth:

100 nm (1260-1360 nm)

Rx Wavelength Bandwidth:

100 nm (1260-1360 nm)

Minimum Transmitting Power:

-8 dB

Maximum Transmitting Power:

-0.5 dB

Receiver Sensitivity:

-14 dBm

Receiver Overload:

0.5 dBm

Dispersion:

70-100 ps/nm

Transmitter Type:

DFB Laser

Receiver Type:

PIN photodiode

Power:

+3.3V single power supply

Chipset:

MAXIM, MINDSPEED, SEMTECH

Compliance:

CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, RoHS, SFF-8431, SFP MSA

Transceiver Type:

SFP+
