Safety function
Sound and light alarm for temperatures above or below the upper or lower limit; alarm for speeds above or below the upper or lower limit; separate over-temperature protector; shutdown protection for door opening; leakage or overcurrent protector.
Additional functions
Storage of rotary speed, startup after power again, recording of parameters, temperature and speed calibration, clock display and display of room temperature and actual temperature.
Programming function
Programing of repetition, steps and eight curves settings
|
Model of products
|
OLT-WB-10(Desktop)
|
OLT-WB-11(Desktop)
|
OLT-WB-12(Horizontal)
|
|
Control mode
|
P.I.D (Microcomputer scans the micro-processing chip)
|
|
Display mode
|
LCD (Double display of large liquid crystal screen)
|
|
Shaking mode
|
Reciprocating oscillating
|
|
Drive mode
|
Track balanced-drive type
|
|
Reciprocating frequency
|
20~200rpm
|
|
Rotary accuracy
|
±1 rpm
|
|
Stroke range
|
Φ25(mm)
|
|
Maximum capacity
|
12×250mLOr 500ml*8
or 1000ml*6
|
24×250mL Or 500ml*15 or1000ml*8
|
48×250ml Or 500ml*30 or 1000ml*20
|
|
Size of shaking plate
|
430×320(mm)
|
590×390(mm
|
780×586(mm)
|
|
Dimensions of spring shaking plate
|
430×320×60(mm)
|
590×390×80(mm
|
780×586×80(mm)
|
|
Timing range
|
0 – 500 hours/continuous
|
|
Temperature control range
|
Ambient temperature 5℃-99.9℃
|
|
Temperature accuracy
|
±0.2℃ (Constant temperature)
|
|
Uniformity
|
±0.1℃
|
|
Number of shaking plate
|
One
|
|
Size of cavity
|
510×380×240(mm)
|
700×455×260(mm)
|
940×660×275(mm)
|
|
Shape size
|
760×420×370(mm
|
945×495×408(mm)
|
1240×700×760(mm)
|
|
Net weight
|
45kg
|
55kg
|
80kg
|
|
Power
|
2000W
|
2200W
|
4000W
|
|
Motor
|
60W Inverter motor
|
|
Material Science
|
316L stainless steel quality
|
|
Voltage
|
AC 200~240V50~60HZ
|
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
1. We will try to reply your inquires in 24 hours.
2. All our sales stuff will stand stand in customer’s position, and service you from the perspective of customers.
3. Most of our machine can be customized, so you can tell your kinds of requirement before ordering. We will try to meet client’s requirement.
4. If need we sales sometimes can’t answer your questions, here we have experienced engineer to assist the sales disambiguation for your answer.
