Specifications
Usage:: Indooris customized: Yes
Model Number: PH 5
Product size/inch: 39X14 inch
Product size/mm: 1000x360 mm
Display language: All the language
Support PC : WinXP, Win7,W8,W10
Plug type: US/EU/UK/AU etc
Package including
*LED sign 1PCS (size 100x36cm / 39x14 inch)
*Signal connection cable
* Professional installation bracket
*USB with free software and English user manual
Feature & Function
|
Model : CX-PH5 RGB02A
|
|
|
|
|
|
LED Module model
|
|
color
|
1R1G1B
|
|
LED Type
|
SMD2121
|
|
Module Resolution
|
W 64 x H 32
|
|
Module Size (mm)
|
W 320 x H 160
|
|
Driving Method
|
1/16 scan
|
|
LED display parameter
|
|
voltage
|
220V or 110V ± 10%
|
|
Material
|
indoor aluminum waterproof ( IP 20 )
|
|
Cabinet Size （mm)
|
W 1000x H360 MM (39X14 Inch)
|
|
Cabinet Resolution (pixel)
|
W 192 x H 64
|
|
power Consumption Max (w/set）
|
200 Watt
|
|
Brightness ( CD/㎡）
|
≥1500
|
|
Net Weight (kg)
|
10kg
|
|
Viewing Angle
|
120° / 70°
|
|
Theoretic LED Working Life
|
More than 100000 hours
|
|
control method
|
USB port control (network, wifi, optional)
|
|
display function
|
Date,Text, picture, logo , video.
|
