rohs listed dc 12v power adapter

rohs adapter;dc adapter 12v;adapter power



rohs listed dc 12v power adapter

Product Description





Model No.

Input (Vac)

output (Vdc)

Current (Amp)

power (Watt)

   Tol.

    R&N

    Effi.

SMT-012-120VP

100-240V

12Vdc

10.00Amp

120W

±4%

100mV

>82%

SMT-024-120VP

100-240V

24Vdc

5.00Amp

120W

±4%

100mV

>82%

SMT-036-120VP

100-240V

36Vdc

3.33Amp

120W

±4%

100mV

>82%

SMT-048-120VP

100-240V

48Vdc

2.5Amp

 120W

±3%

200mV

>82%

  • Fully enclosed plastic case
  • Class I power (with earth pin)
  • Pass LPS for 16~48V
  • Full output 5~120V safety approved
  • LED indicator for power on
  • Protections: Short circuit / Overload /
  • Approvals: CE / RoHS

General Specification

  • AC input voltage range ............. 100~265VAC / 5A
  • AC inrush current (max.) ...........Cold start, <40A at 230VAC
  • Overload protection................... Hiccup mode, auto-recovery
  • Over voltage protection .............110~140% rated output voltage
  • Hold up time...............................16ms at full load
  • Withstand voltage...................... I/P-O/P: 4242VDC, 1minute
  • Working temperature..................0~40°C @ 100% load, 50°C @ 70% load
  • Safety standards........................ TUV EN60950-1 approved
  • EMC standards.......................... EN55022-B, EN61000-3-2,3, EN61347-1
  • Length of output cable................180cm of SPT-1,18AWG x2C
  • Standard DC plug....................... P2J: 2.1x5.5x10mm / C+, barrel type

Environment :

  • Working Temperature : -25 ~ +50°C
  • Working Humidity : 20 ~ 90% RH non-condensing
  • Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
  • TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
  • Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

Safety :

  • Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
  • Withstand Voltage : I/P-O/P: 3000KVAC
  • Isolation Resistance : I/P-O/P:100M Ohms/500VDC

Applications:

  • indoor LED illuminating lights, LED Neon
  • LED urban Decoration,LED Lighting Advertising
  • LED Display, Safety Protection Apparatus
  • Telecommunications, Networks
  • Vehicle Lights, Controller Panels
  • Want to get more DC 12v Power Adapter product information, welcome to view more! Any question, please feel free to contact us.
