Feature:
◆Support ISO18000-6C Gen 2 protocol;
◆Stable reading to 25m(with external 12dbi antenna, Alien
H3 9662 tag)
◆Excellent ability of reading and writing, better to
prevent collision;
◆Support multiple frequency standard
◆Good heat dissipation effect to ensure the
stability of equipment
Specification:
|
Item No.
|
JT-916
|
|
Performance parameters
|
|
|
Working Frequency
|
902~928 MHz or 865~868MHz
|
|
Protocol
|
ISO18000-6C(EPC C1 GEN2)
|
|
Output power
|
15~30dBm(Adjustable)
|
|
Reading Range
|
With white card & 12dBi
antenna, 30m
|
|
RF port
|
Four-way SMA-Female
|
|
Communication Protocol
|
Asynchronous serial port
|
|
UART port
|
Baud Rate 115200, TTL
|
|
USB port
|
One-way USB2.0 all speed port
|
|
Current rating
|
Max 1A
|
|
Standby current
|
<60mA
|
|
Physical parameters:
|
|
|
Item size
|
100x120MM
|
|
Net weight
|
12g
|
|
Working temperature
|
-20℃~+50℃
|
|
Storage temperature
|
-30℃~+75℃
|
|
Operating power
|
DC3.7V~5V
|
